- Page 1 SW36XFAV2 active subwoofer USER MANUAL revision 2023-09-15...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS Watch for these symbols: The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure, that may be of sufficient magnitude to constitute a risk of electric shock to persons.
- Page 3 FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
-
Page 4: Table Of Contents
The SW36XFAV2 subwoofer system is equipped with two high power 18” (460mm) transducers capable of very long excursion (up to 30mm peak-to-peak), and featuring a a large displacement suspension system. These transducers use Tetracoil technology, where two different, axially separated magnetic gaps and two inside-outside 100mm (4”... -
Page 5: Mechanical Drawing
Neutrik Powercon® TRUE1 (for power in)* AXFEETKIT Kit made of 6pcs BOARDACF01 foot NAC3MX-W-TOP-L Neutrik Powercon® TRUE1 (for power out)* KPTSW36XF Fly bar for Axiom SW36XF and AX2010 Loudspeakers HTLACA Tool for tightening powerCON TRUE1* AC103GS 100 mm Swivel castor without brake... -
Page 6: Spare Parts
SPARE PARTS 91AMDSW36V2 91DALITEMOD4HV Amplifier module assembly Powersoft LITEMOD4HV amplifier module NAC3PX-TOP Neutrik Powercon® TRUE1 inlet-outlet 98AXM218TLW4 18’’ woofer - 4” Tetracoil® dual voice coil - 4 ohm SCNAC-04 Neutrik Rubber Sealing for NAC3PX 95AXM014 Locking Pin for AX2010 91DSPKT11 Input, Control and CORE2 DSP PCBA I/O AND CONTROL OPERATIONS MAINS~ IN... -
Page 7: Preset Button
This PRESET is suitable for any application where low frequency reinforcement is required. The response starts at 45Hz and the cutoff is at 100Hz with LR 24dB/oct., use this preset for almost any application at ground stack and it must be used with the SW36XFAV2 set as flown (see FLOWN SET UP). INFRA This PRESET can be used when a deeper bass response is required (Note that when this preset is used the sound pressure level of the system is slightly reduced). -
Page 8: Pronet Ax
Download the PRONET AX app registering on MY AXIOM at the website at https://www.axiomproaudio.com/. The AXIOM active loudspeaker devices can be connected in a network and controlled by the PRONET AX software, for the network connection the USB2CAND (with 2-port) converter optional accessory is needed. -
Page 9: Prediction Software: Ease Focus 3
AFMG Technologies GmbH. It is based on the EASE GLL loudspeaker data file required for its use. The GLL file contains the data that defines the Line Array with regard to its possible configurations as well as to its geometrical and acoustical properties. Download the EASE Focus 3 app from the AXIOM website at https://www.axiomproaudio.com/ clicking on downloads section of the product. -
Page 10: Aiming And Suspending Instructions (Flown Set Up)
The SW36XFAV2 subwoofers can be suspended alone or at the top of a vertical array of AX2010A loudspeakers using the KPTSW36 fly bar. The boxes are linked together in a column using a series of couplers integrated in the frame of each enclosure. Each system can be set properly both acoustically and mechanically, using the aiming software. - Page 11 (see figure): the backward position is to link another SW36XFAV2 box, the forward position is to link a AX2010A box.
- Page 12 KPTSW36 - SW36XFA - SW36XFA ARRAY ASSEMBLING SEQUENCE MAX: KPTSW36 8x SW36XFA...
- Page 13 KPTSW36 - SW36XFA - AX2010A ASSEMBLING SEQUENCE MAX: KPTSW36 2x SW36XFA 12x AX2010A...
-
Page 14: Cardioid Set Up
CARDIOID SET UP The cardioid preset must be used in a sub array of three SW36XFAV2. Two box must be oriented towards the audience and one must be turned in the opposite direction (typically the box in the centre of the array). The bottom and the top boxes must have the STANDARD PRESET, the box in the middle must have the CARDIOID PRESET. - Page 15 bass cancellation direction stage wall or other big ostacle 80 cm min. 2.7 ft min. 80 cm min. 80 cm min. use the AXFEETKIT (optional) 2.7 ft min. 2.7 ft min. on all the SW36XFA which permit audience floor to slot in the boxes bass sum direction NOTES: When placing the cardioid array keep a distance to walls or other obstacles of at least 80 cm (2.6 ft) in order not to affect the radiation of the...
- Page 16 PROEL S.p.A. (World Headquarters) - Via alla Ruenia 37/43 - 64027 Sant’Omero (Te) - ITALY Tel: +39 0861 81241 Fax: +39 0861 887862 www.axiomproaudio.com...
