- Page 1 SW212A Active Subwoofer USER MANUAL revision 2021-11-03...
- Page 3 IMPORTANT SAFETY INSTRUCTIONS Watch for these symbols: The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure, that may be of sufficient magnitude to constitute a risk of electric shock to persons.
- Page 4 FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
-
Page 5: Table Of Contents
SPEAKON. The built-in CORE2 DSP provides 4 presets for different combinations: 2, 4 or 1 columns plus 1 user preset (additional presets for processing other AXIOM speakers are also available). The SW212A features on the top panel a special metal plate and it comes with a dedicated bracket for fast coupling with the AX16CL’s rigging hardware. -
Page 6: Mechanical Drawing
MECHANICAL DRAWING 70.0 cm 71.0 cm 27.9" 27.6" Adjustable feet (turn to adjust the height) OPTIONAL ACCESSORIES NAC3FXWTOP NE8MXB Neutrik Powercon® TRUE1 (for power in)* Neutrik Ethercon PLUG* (carrier only for pre-made cables) NAC3MXWTOP Neutrik Powercon® TRUE1 (for power out)* NE8MX6BT Neutrik Ethercon PLUG* (crimping CAT6a connector) NC3MXXBAG... -
Page 7: I/O And Control Operations
I/O AND CONTROL OPERATIONS MAINS IN Powercon® NAC3FXWTOP power inlet connector. To switch the amplifier on, insert the Powercon® connector and turn it clockwise into the ON position. To switch the amplifier off, pull back the switch on the connector and turn it counter-clockwise into the POWER OFF position. MAINS OUT Powercon®... -
Page 8: Link
LINK A direct connection from the input connector to link other speakers with same audio signal. GND LIFT This switch lift the ground of the balanced audio inputs from the earth-ground of the amplifier module. PRESET BUTTON This button has two function: 1) Pressing it while powering on the unit: ID ASSIGN The internal DSP assigns a new ID to the unit for the PRONET AX remote control operation. -
Page 9: Pronet Ax Operation
With PRONET AX you can visualize signal levels, monitor internal status and edit all the parameters of each connected device. Download the PRONET AX app registering on MY AXIOM at the website at https://www.axiomproaudio.com/. For the network connection the USB2CAN-D (with 2-port) converter optional accessory is needed. -
Page 10: Prediction Software: Ease Focus 3
Download the EASE Focus 3 app from the AXIOM website at https://www.axiomproaudio.com/ clicking on downloads section of the product. Use the menu option Edit / Import System Definition File to import the GLL file, the detailed instructions to use the program are located in the menu option Help / User’s Guide. -
Page 11: Pin Locking And Splay Angles Set Up
PIN LOCKING AND SPLAY ANGLES SET UP The figure below shows how to insert correctly the locking pin and how to set up the splay angle between loudspeakers. LOCKING PIN INSERTION AX16CL and AX8CL column to column SW212A and AXCL sub to column press and release and... -
Page 12: Stacked Installation Using Sw212A Subwoofer As Base
STACKED INSTALLATION USING SW212A SUBWOOFER AS BASE WARNINGS: • The ground where the SW212A is placed needs to be absolutely stable and compact. • Adjust the feet so to lie the SW212A perfectly horizontal. Use a spirit level to obtain the best result. •... -
Page 13: Sw212A + Ax16Cl Connection Examples
SW212A + AX16CL CONNECTION EXAMPLES The following examples shows all the possible connections between the SW212A amplified subwoofer and the AX16CL column speaker, using the PRESETs availble in the subwoofer’s DSP. Note that one AX16CL unit correspond to two AX8CL units. SW212A + 1 x AX16CL set preset 1 x AX16CL 4 x 4mm²... - Page 14 SW212A + 4 x AX16CL 1+/1- ESO2500LU05 - lenght 0,25m 1+/1- 1+/1- ESO2500LU05 - lenght 0,25m 1+/1- 1+/1- ESO2500LU05 - lenght 0,25m 1+/1- set preset 4 x AX16CL 4 x 4mm² speaker cable 1+/1- 1+/1- ESO2500LU2 - lenght 2m ESO2500LU15 - lenght 15m ESO2500LU5 - lenght 5m ESO2500LU20 - lenght 20m ESO2500LU10 - lenght 10m...
