TransAct Ithaca 93PLUS Specifications page 2

priNTiNG characTerisTics
Printing style:
Pitch (char./in.):
Characters/line (maximum):
Print speed (lines/sec.):
physical characTerisTics
Dimensions (in mm.):
Dimensions (in inches):
Weight:
Shipping Weight:
models
93PLUS Receipt/Journal/17-line Validation/Slip
94PLUS Receipt/17-line Validation/Slip
iNTerface opTioNs
RS232C:
IEEE1284:
priNTer drivers
Windows 95/98/2000/Me, NT 4.0, OPOS
TM
opTioNs
Adjustable Paper Width Options: 76.2 mm, 82.5 mm (3.0 in., 3.25 in.)
n
Banking Validation: 10 lines, drop-in
n
Concurrent and Independent Validation (Up to 17 Lines Under Software
n
Control): M93, M94
Auto-Cut: Partial Cut leaves a 1 mm (.04 in.) tab in center of receipt.
n
Journal Lock
n
slip capaBiliTies
Rotated Print (4-90° rotations)
n
Programmable Top of Form
n
Automatic Forms Detection and Feed Under Software Control
n
Top of Form to Top of Print Line: 15.8 mm (.625 in.)
n
Bottom of Form to Bottom of Print Line: 15.8 mm (.625 in.)
n
poWer reQUiremeNTs
Internal Universal AC Power: 90 VAC to 264 VAC (self-ranging), 47 to 63 Hz
reliaBiliTy
Printer in full operation (using all available features)*
MCBF:
MTBF:
Printhead:
Auto-Cutter:
*Reliability data is based on our standard test conditions simulating a
normal retail operating environment.
eNviroNmeNTal specs
Temperature: Operating: 0 to +50 °C (32 to +122 °F)
Humidity: Operating: 10 to 90% RH (non condensing)
reGUlaTory compliaNce
FCC Class A CSA 950
©2008 Transact Technologies, Inc. Contents of this publication may
be changed without notice and shall not be regarded as a warranty.
The Epic 430TM name and logo are registered trademarks of TransAct
Technologies. Windows is a registered trademark of Microsoft
Corporation. All rights reserved. Patent pending.
Condensed
17.1
48
12.5 @ 10 char./line; 5.9 @ 40 char./line
185.42 W x 311.15 D x 152.40 H
7.3 W x 12.25 D x 6.0 H
10 lbs. (4.5 Kg)
13 lbs. (5.9 Kg)
Bi-Directional Serial (9-pin)
Bi-Directional Parallel (25-pin)
4,000,000 to 5,000,000 Print Lines
(depending on model)
22,000 to 30,000 Hours
(depending on model)
200,000,000 Characters
1,000,000 Cuts
CEMark UL 1950
sUpplies & service
We offer convenient one-stop shopping for all your printer needs-paper,
spare parts, manuals, printer servicing/refurbishment and more. For more
information, call us at 1-877-748-4222 or visit transact-tech.com.
feaTUres aNd BeNefiTs
Print Speed: 12.5 lps. (340 cps.)—On Standard Test Receipt
n
Standard Warranty: Two Years (Extended Maintenance Plan Available)
n
Cash Drawer Drivers: Dual with Status (RJ11)
n
Print Zone: Width: 71 mm (2.8 in.)—Operator Visible
n
Data Buffer: Up to 6K Configurable
n
Custom Logo Print Buffer: (Non-volatile Memory, 2000 Bytes)
n
CPI: 4, 5, 6, 7.5, 8, 8.5, 10, 12, 15, 17.1, 20, 24
n
Portrait or Landscape Printing
n
APA Bit Map Graphics
n
Emulations: Ithaca/IBM, Epson ESC/POS*
n
67 Language Code Pages
n
Optical Paper Low Switch (Software Sense and Adjustable)
n
Concealed Cable Entry
n
Forms Insertion: Front (Slip) or Top (Validation)
n
Display Pass-Thru (Serial Only)
n
Bar Codes: Code 39, Interleaved 2 of 5, UPC-A & UPC-E, EAN8 & EAN13,
n
Code 128
Interface Parameters: Software Configurable via Buttons or Interface Port
n
* Automatic Status Back feature available as an option.
media
Paper Roll (one-ply):
Width: 82.5 mm (3.25 in.) or optional 76 mm (3 in.)
n
Diameter: 89 mm (3.5 in.)
n
Length Per Roll: 73.1 m (240 ft.)
n
One-Ply Maximum Thickness: .11mm (.0045 in.)
n
Paper Roll (two-ply):
Width: 82.5 mm (3.25 in.)
n
Diameter: 89 mm (3.5 in.)
n
Length Per Roll: 38.1 m (125 ft.)
n
Maximum Thickness Per Ply: .09 mm (.0035 in.)
n
Paper Roll (Three-Ply):
Width: 82.5 mm (3.25 in.)
n
Diameter: 89 mm (3.5 in.)
n
Length Per Roll: 26m (85 ft.)
n
Maximum Thickness Per Ply: .25 mm (.01 in.)
n
Inserted Forms (1 original and up to 3 copies):
Minimum form size: 63.5 mm W x 85.73 mm L (2.5 in. W x 3.375 in. L)
n
Single sheet thickness: .09 mm - .41 mm (.0035 in - .016 in.)
n
Multi-part form maximum thickness: .41 mm (.016 in.)
n
Ribbons: 3-4.5 Million Character Life
Ithaca or Genuine Oki Snap-on Ribbon Cassette (Black or Purple)
