HN300 Valve Left/Seat Right Shown
Read the entire installation manual to ensure proper installation of your HN300 shower. When finished
with the installation, file this manual with the owner maintenance department. Compliance and conformity
to local codes and ordinances is the responsibility of the installer.
Consult local building and plumbing codes prior to installation. Should these codes differ from the
information in the Manual, follow the local codes. Inquire with governing authorities for additional local
requirements.
Separate parts from packaging and make sure all parts are accounted for before discarding packaging
material. If any parts are missing, do not begin installation until you obtain the missing parts.
Product warranties may be found under "Products" on our website at bradleycorp.com
215-466 Rev. H: ECO 19-03-031
© 2019 Bradley
Page 1 of 6 11/15/2019
Installation
HN300 ADA Compliant
In-Wall Shower
Table of Contents
Pre-Installation Information . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Components and Shower Stall Dimensions . . . . . . . . . . . . . 2
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Cleaning Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Repair Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
IMPORTANT
P.O. Box 309
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
+1 262 251 6000
www.bradleycorp.com
Advertisement
Table of Contents
Related Manuals for Bradley HN300
Summary of Contents for Bradley HN300
- Page 1 HN300 Valve Left/Seat Right Shown IMPORTANT Read the entire installation manual to ensure proper installation of your HN300 shower. When finished with the installation, file this manual with the owner maintenance department. Compliance and conformity to local codes and ordinances is the responsibility of the installer.
- Page 2 Pre-Installation Information Overview The Bradley ADA compliant HN300 shower is an ideal solution to barrier-free or ADA compliant shower room design . The HN300 blends in well with other wet tile shower fixtures - avoiding any connotation of a "special" handicapped unit .
- Page 3 (From Floor) Dimensions for placing components for Recessed 36" Max to meet accessibility Soap Dish 33" Min . 7" requirement codes. Top of Grab Bar Conformance is the responsibility of the installer. Floor Bradley • 215-466 Rev. H: ECO 19-03-031 11/15/2019...
- Page 4 3 . Install two wall anchors (supplied by installer) for #10-24 screws at two screw hold locations . It is the installer's responsibility to use the correct anchors for the given wall construction. 4 . Secure hose bracket to wall anchors using two #10-24 screws supplied . Bradley • 215-466 Rev. H: ECO 19-03-031 11/15/2019...
- Page 5 . A steel nail or screw may be the cause of the trouble . 4 . If the showerhead delivers an uneven spray, remove the showerhead from the unit, disassemble and remove foreign matter . 5 . Reassemble showerhead and reinstall into unit . Bradley • 215-466 Rev. H: ECO 19-03-031 11/15/2019...
- Page 6 Shower Rod Flange (2) P10-412* #10-13 x 2" Phillips Head Swivel Grab Bar Screw (4) Connector (8120-0592436) (169-943) 170-006* Vinyl Shower Curtain 170-006E Herculite Shower Curtain *Also available in Curtain Prepack S30-068 . Bradley • 215-466 Rev. H: ECO 19-03-031 11/15/2019...
