Technical Support and E-Warranty Certificate
www.vevor.com/support
FIBER CEMENT BACKERBOARD SHEAR
USER MANUAL
We continue to be committed to offering tools at competitive prices. "Save Half", "Half Price",
or any other similar expressions used by us only represent an estimate of savings you might
benefit from buying certain tools with us compared to the major top brands and do not
necessarily mean to cover all categories of tools offered by us. You are kindly reminded to
verify carefully when placing an order with us if you are saving half in comparison with the top
major brands.
Advertisement
Related Manuals for VEVOR DR24
Summary of Contents for VEVOR DR24
- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support FIBER CEMENT BACKERBOARD SHEAR USER MANUAL We continue to be committed to offering tools at competitive prices. "Save Half", "Half Price", or any other similar expressions used by us only represent an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and do not necessarily mean to cover all categories of tools offered by us.
- Page 2 CustomerService@vevor.com This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software...
- Page 3 The symbols used in this manual are intended to alert you of the possible risks. Please fully read the safety signs and instructions below. The warning themselves do not prevent the risks and can not be a substitute for proper methods of avoiding accidents.
-
Page 4: Product Specifications
PRODUCT SPECIFICATIONS FIBER CEMENT BACKERBOARD SHEAR Model DR24 Blade Material ADC12 Shank Size 1/4”Hex Materials to cut Fiber Cement Board Plasterboard Cutting capacity 13mm Fiber Cement Board,12mm Plasterboard FIBER CEMENT BACKERBOARD SHEAR FIBER CEMENT BACKERBOARD SHEAR WARNING: READ AND UNDERSTAND THESE INSTRUCTIONS and the instructions for the power tool used with this product. - Page 5 DO NOT use under wet conditions or in the presence of flammable liquids or gases. DO NOT let children come into contact with the shear. Supervision is required when inexperienced operators use this tool. DO NOT hold the shear attachment as a primary gripping surface. ·...
- Page 6 b. Rotate the knobs(3)on both sides to loosen the clamp. Then adjust the length of the clamp by pulling or pushing on the length adjusting lever (4) of the telescoping clamp. c. Lock at the desired length/width by pushing the lock(2)located at the end of the telescoping clamp.
- Page 7 1.For an attractive hand-cut appearance,hold tile piece finished-side-up when using the drill attachment to make straight,angled or curved cuts in natural roofing slate. 2.Start angled cuts at the narrow end to avoid chipping off the point. 3.Make sure that the shear's padded skid plate is flush to the tile and that the shear attachment is operating at a drill speed 0f 1400 to 2000RPM.
- Page 8 HOW TO MAINTAIN YOUR SHEAR Step 1: Disassemble the gear box Step2. Clean the inside of gearbox witsmall Brush Step3. Add some grease.(NLGI2-3level grease is recommended) Step4. Re-assembly...
-
Page 9: Exploded View
EXPLODED VIEW PARTS LIST WARNING! When servicing, use only original equipment replacement parts. The use of any other parts may create a safety hazard or cause damage to the tool. Any attempt to repair or replace electrical parts on this tool may create a safety hazard unless repairs are performed by a qualified technician. - Page 10 Connecting link Rubber plug Locking bracket Parallel pins Width adjusting bracket Locking buckle GearBox Check Ring Ball bearning Hexagon head bolts Output shaft Trolley Hose clamps Movable blade Washer Fixed blade Plastic sliding strip cross recessed countersunk head screws Washer GEARBOX Prevailing torque type hexagon nut Washer...
- Page 11 Address:Baoshanqu Shuangchenglu 803long 11hao 1602A-1609shi Shanghai Imported to AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD NSW 2122 Australia Imported to USA: VEVOR STORE INC, 9448 RINCHMOND PL #E RANCHO CUCAMONGA, California, 91730 United States of America...
- Page 12 Technical Support and E-Warranty Certificate www.vevor.com/support...
