- Page 1 Ruijie RG-S6000C-48GT4XS-E-AC(DCN) Switch Hardware Installation and Reference Guide...
- Page 2 This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to co ntent omissions, inaccuracies or errors.
- Page 3 It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts. Obtaining Technical Assistance Ruijie Networks Website: https://www.ruijienetworks.com/ Technical Support Website: https://ruijienetworks.com/support...
-
Page 4: Product Overview
Hardware Installation and Reference Guide Product Overview Product Overview Ruijie RG-S6000C-48GT4XS-E-AC(DCN) IPv6 switch supports high-density 10G port scalability, mainly applied to data center scenarios. RG-S6000C-48GT4XS-E-AC(DCN) switch provides aggregation and access services for servers with 10G ports. 10/100/1000 1000M Mini Expansion... - Page 5 8 MB Flash Memory 512 MB SDRAM 1 GB See Appendix B. Optical Module The supported module type may change at any time. Consult Ruijie Networks for the latest information. Expansion Module 1 slot Slot Supported expansion module: M6000E-04XS ...
- Page 6 Hardware Installation and Reference Guide Product Overview The S6000C-48GT4XS-E-AC(DCN) Ethernet switch provides 48 10/100/1000Base-T Ethernet ports, 4 10GE SFP+ ports, 1 MGMT port, 1 USB port, 1 Mini USB port, and 1 Console port on the front panel, as well as 2 power module slots, 1 expansion module slot and 1 fan module slot on the back panel.
- Page 7 Hardware Installation and Reference Guide Product Overview Note: 1. Grounding connector 4. Power module slot 1 2. Expansion module slot 5. Power module slot 2 3. Fan module slot Power Supply The RG-S6000C-48GT4XS-E-AC(DCN) supports two power modules. For details, see the section “Power Modules ”. Dual-power input: The switch can be powered by one power module, or two power modules.
- Page 8 Hardware Installation and Reference Guide Product Overview Panel Identification State Meaning The switch is not receiving power. Blinking green The switch is being initialized with 3Hz blinking. (3 Hz) Continuous blinking indicates errors. Blinking green Supports remote on/off to locate the switch. (10Hz) Solid green The switch is operational.
-
Page 9: Expansion Modules
Hardware Installation and Reference Guide Product Overview Panel Identification State Meaning Ethernet port status Solid green The port is connected at 1000 Mbps . The port is receiving or transmitting traffic at Blinking green 1000 Mbps. Solid yellow The port is connected at 10/100 Mbps. The port is receiving or transmitting traffic at Blinking yellow 10/100 Mbps. - Page 10 Hardware Installation and Reference Guide Product Overview Operating altitude: 0 m to 5,000 m Altitude Storage altitude: 0 m to 10,000 m Features Feature Description Conformal Coating Protects circuits against moisture, frog, mould, electrical shock and leakage, and so on. Provides protection over over-voltage/current input/output, short-circuit output and so Protection I2C Communication...
-
Page 11: Fan Module
Hardware Installation and Reference Guide Product Overview system, plug and unplug power modules while the device is powered on. Power Supply Alarm Monitors power supply status and generates alarms through the power status LED. Panel Identification State Meaning There is no power output or an error occurs. Status LED Solid green The module is operational. -
Page 12: Preparation Before Installation
Hardware Installation and Reference Guide Preparation before Installation Preparation before Installation Safety Suggestions To avoid personal injury and equipment damage, please carefully rea d the safety suggestions before you install the RG-S6000C-48GT4XS-E-AC(DCN) switch. The following safety suggestions may not cover all possible dangers. 2.1.1 Installation ... - Page 13 Hardware Installation and Reference Guide Preparation before Installation Direct or indirect touch through a wet object on high-voltage and commercial electricity may bring a fatal danger. If a power supply system is equipped with a leakage protector (also referred to as "leakage current switch" or "leakage current breaker"), the rated leakage action current of each leakage protector is greater than twice of the theoretical maximum leakage current of all the power supplies in the system.
-
Page 14: Installation Site Requirements
Hardware Installation and Reference Guide Preparation before Installation Do not approach or stare into any optical port, as this may cause permanent damag e to your eyes. Installation Site Requirements The RG-S6000C-48GT4XS-E-AC(DCN) switch must be used indoors. To ensure its functioning and prolong its service life, the installation site must meet the following requirements. - Page 15 Hardware Installation and Reference Guide Preparation before Installation should be protected from the intrusion of harmful gases (for example, SO S, NO and Cl ), whose requirements are listed in the following table. Average (mg/m Maximum (mg/m 2.2.4 Grounding A good grounding system is the basis for the stable and reliable operation of the RG-S6000C-48GT4XS-E-AC(DCN) switch, preventing lightning stroke and resisting interference.
-
Page 16: Lightning Resistance
Hardware Installation and Reference Guide Preparation before Installation 2.2.5 Lightning Resistance When the AC power cable is imported outdoors and directly connected to the power port of the switch, lightning preventing wires should be adopted to prevent the switch from being hit by lightning shocks. The lightning preventing wires can be fixed on the cabinet, work station, or the equipmen t room’s wall through line buckles and screws. -
Page 17: Inspection After Unpacking
Hardware Installation and Reference Guide Preparation before Instal lation RG-S6000E is not provided with a tool kit. Please prepare tools on your own. Inspection after Unpacking Packing Items Mainframe Box Mainframe, grounding wire, quick start guide, packing list, other materials Module Box Module, quick start guide, packing list A normal delivery should contain the above mentioned items, which may differ from the actual delivery,... -
Page 18: Product Installation
Hardware Installation and Reference Guide Product Installation Product Installation Please ensure that you have carefully read Chapter 2 and make sure that the requirements set forth in Chapter 2 have been met. Installation Flowchart Pre-installation Confirmation Before installation, please confirm the following points: ... -
Page 19: Installing The Switch
Hardware Installation and Reference Guide Product Installation Installing the Switch Precautions During installation, note the following points: Connect the power cables of different colors to the corresponding grounding posts. Ensure that the connected power cables have sound contact. ... -
Page 20: Mounting The Switch On A Table
Hardware Installation and Reference Guide Product Installation 3.3.3 Mounting the Switch on a Table For often, users may not have a 19-inch rack. Thus, it is common to mount the switch on the workbench with 2 simple steps: Attach the four rubber feet to the recessed areas on the bottom of the switch. ... - Page 21 Hardware Installation and Reference Guide Product Installation Insert the power module smoothly. Please pay attention to the direction of the power panel to avoid wrong insertion. If the module is not correctly inserted, pull it out and then insert it again. If the screws cannot be tightened, it is probably because the fan module is not fully inserted.
- Page 22 Hardware Installation and Reference Guide Product Installation Step 2: Pinch the captive screws on M6000E. Align M6000E to the guide rail of the expansion module port, and push it to the switch along the rail horizontally and slowly. Step 3: Tighten the captive screws with a screwdriver to fix M600E in the switch chassis. Figure 3-5 Installing an Expansion Module Insert the expansion module smoothly.
- Page 23 Hardware Installation and Reference Guide Product Installation Withdraw the expansion module uprightly and slowly. Do not hold the edge of the PCB or collide the components on the PCB. Install a blank panel on the location where an expansion module is removed to ensure normal ventilation and dissipation and avoid dust in the chassis.
- Page 24 Hardware Installation and Reference Guide Product Installation Insert the power module smoothly. Please pay attention to the direction of the power panel to avoid wrong insertion. If it is difficult or even impossible to insert the module, pull out the module, make sure the expansion module and guide rail are well aligned, and then insert the m odule again.
- Page 25 Hardware Installation and Reference Guide Product Installation Figure 3-9 Installing a Power Module Step 3: Connect the other end of power cord to DC terminal board. The blue end connects to -48VDC, the red end connects to -48VGND, and the yellow-green end connects to PGND. Figure 3-10 Cord Connection on DC Terminal Board Insert the power module smoothly.
-
Page 26: Grounding The Switch
Hardware Installation and Reference Guide Product Installation Figure 3-11 Removing a Power Module Step 3: Put the removed power module and cord into its package. Grounding the Switch RG-S6000E has a PGND on the back panel. First connect the PGND to the grounding lug of the rack and then connect the grounding lug to the grounding bar of the equipment room. -
Page 27: Connecting The External Port Cables
Hardware Installation and Reference Guide Product Installation Connecting the External Port Cables Precautions Correctly distinguish single-mode and multi-mode fibers and ports. Avoid bends of small radius at the connector. Steps Step 1: Connect one end of the RJ45 connector to the Ethernet interface of the device board (MGMT), and the other end to the NMS or a control terminal. -
Page 28: System Commissioning
Hardware Installation and Reference Guide System Commissioning System Commissioning Establishing the Configuration Environment Establishing the Configuration Environment Use the Console cable to connect the PC to the switch. Figure 4-1 Configuration Environment Connecting the Console Cable The RG-S6000C-48GT4XS-E-AC(DCN) switch supports the following connecting ways: Step 1: Connect the serial &... - Page 29 Hardware Installation and Reference Guide System Commissioning Setting Terminal Parameters Step 1: Start the PC and run the terminal simulation program on the PC, such as Terminal on Windows 3.1 or HyperTerminal on Windows 95/98/NT/2000/XP. Step 2: Set terminal parameters. The parameters are as follows: baud rate 9600, data bit 8, parity check none, stop bit 1, and flow control as none.
-
Page 30: Power-On Startup
Hardware Installation and Reference Guide System Commissioning After choosing the series port, click OK to display the series port parameter setting page, set the baud rate at 9600, data bit at 8, parity check as none, stop bit at 1 and flow control as none. Figure 4-4 After setting the parameters, click OK to enter the super terminal page. -
Page 31: Monitoring And Maintenance
Hardware Installation and Reference Guide Monitoring and Maintenance Monitoring and Maintenance Monitoring LED When the RG-S6000E is running, users can monitor the status of mainframe and each module by inspecting corresponding LEDs . When the system status LED is red, it means the system has a fault, in which case you can determine and eliminate the fault by viewing with the management software. -
Page 32: Hardware Maintenance
Please contact the TAC of Ruijie Networks for replacing lithium batteries. Technical staff of Ruijie Networks will replace the battery of the same model. Replacing Fuses Please contact the TAC of Ruijie Networks for replacing fus es. Technical staff of Ruijie Networks will replace the fuse of the same model. -
Page 33: General Troubleshooting Flowchart
Fault 1: The password to login the management interface is lost. Fault Description: A password is manually configured but it is forgotten or lost, causing failure in login and configuration. Troubleshooting: Contact TAC of Ruijie Networks for technical support. Fault 2: The AC power module does not work. Fault Description:... - Page 34 Configuration Guide. If not, modify the serial port configuration parameters. If there is still no serial port printed information, please contact TAC of Ruijie Networks for technical support. Fault 4: The serial port console outputs illegible characters.
- Page 35 Hardware Installation and Reference Guide Troubleshooting Check whether the receiving and sending ends are wrongly connected. The sending end of the fiber interface needs to be connected to the receiving end of the other fiber interface. You can check by changing the sequence in which the two optical fibers are connected on the optical modu le.
-
Page 36: Appendix A Connectors And Connection Media
Hardware Installation and Reference Guide Appendix A Connectors and Connection Media Appendix A Connectors and Connection Media 1000BASE-T/100BASE-TX/10BASE-T Ports The 1000BASE-T/100BASE-TX/10BASE-T is a port that supports adaptation of three rates, and automatic MDI/MDIX Crossover at these three rates. The 1000BASE-T complies with IEEE 802.3ab, and uses the cable of 100-ohm Category-5 or Supper Category-5 UTP or STP, which can be up to 100 m. - Page 37 Hardware Installation and Reference Guide Appendix A Connectors and Connection Media Figure A-4 Schematic Diagram for optical fiber connection...
-
Page 38: Appendix B Mini-Gbic And 10G Sfp+ Modules Specifications
Appendix B Mini-GBIC and 10G SFP+ Modules Specifications Ruijie Networks provides various Gigabit SFP (Mini-GBIC modules), and 10G SFP transceivers for interfaces of modules on the switch. You can select the most suitable SFP transceivers as needed. This appendix describes the models and specifications of some of the Gigabit and 10G SFP transceivers for your reference. - Page 39 Hardware Installation and Reference Guide Appendix B Mini-GBIC and 10G SFP+ Modules Specifications Core Size (μm) Model Interface Type Fiber Type Cabling Distance 62.5/125 275 m MINI-GBIC-SX-MM850 50/125 550 m MINI-GBIC-LX-SM1310 9/125 10 km 62.5/125 275 m GE-eSFP-SX-MM850 50/125 550 m GE-eSFP-LX-SM1310 9/125 10 km...
- Page 40 Hardware Installation and Reference Guide Appendix B Mini-GBIC and 10G SFP+ Modules Specifications Mini-GBIC-GT Catogary-5 or above UTP/STP 100 m 10G SFP+ Models and Specifications Table B-4 Existing 10G SFP+ models supported: Wavelength Transmit (dBm) Receive (dBm) Model Fiber Type (nm) (Yes/No) XG-SFP-SR-MM850...
- Page 41 Hardware Installation and Reference Guide Appendix B Mini-GBIC and 10G SFP+ Modules Specifications For supported SFP+ models may change at any time, contact Ruijie Networks after-sales personnel for the latest information. SPF+ copper cables can be inserted to ports directly without the help of other cables.
-
Page 42: Appendix C Lightning Protection
Hardware Installation and Reference Guide Appendix C Lightning Protection Appendix C Lightning Protection Installing AC Power Arrester (lightning protection cable row) The external lightning protection cable row shall be used on the AC power port to prevent the switch from being struck by lightning when the AC power cable is introduced from the outdoor and directly connected to the power port of the switch. - Page 43 Hardware Installation and Reference Guide Appendix C Lightning Protection During the switch usage, the Ethernet port arrester shall be connected to th e switch to prevent the switch damage by lightning before the outdoor network cable connects to the switch. Tools: Cross or straight screwdriver, Multimeter, Diagonal pliers Installation Steps: ...
- Page 44 Hardware Installation and Reference Guide Appendix C Lightning Protection Arrester Hardware Installation Guide, which contains the technical specification and the maintenanc e and installation of the arrester. You may pay attention to the following conditions during the actual installation to avoid influencing the performance of the Ethernet port arrester: ...
-
Page 45: Appendix D Cabling Recommendations
Hardware Installation and Reference Guide Appendix D Cabling Recommendations Appendix D Cabling Recommendations When the RG-S6000C-48GT4XS-E-AC(DCN) switch is installed in standard 19-inch racks, route cable bundles upward or downward along the sides of the rack depends on the actual situation in the equipment room. All cable connectors should be placed at the bottom of the rack rather than be exposed outside of the cabinet. - Page 46 Hardware Installation and Reference Guide Appendix D Cabling Recommendations Route and bundle power, signal, ground cables separately. When the cables are close to each other, cross them. When power cables run parallel to signal cables, the distance between them must b ...
- Page 47 Hardware Installation and Reference Guide Appendix D Cabling Recommendations Leave a certain length of the cable connecting moving pa rts, such as the ground wire of the cabinet door, to avoid stress on the cable; when moving parts are in place, ensure the excess cable length shall not contact heat sources, sharp corners or edges.
-
Page 48: Appendix E Site Selection
Hardware Installation and Reference Guide Appendix E Site Selection Appendix E Site Selection The machine room should be at least 5km away from the heavy pollution source such as the smelter, coal mine and thermal power plant, 3.7km away from the medium pollution source such as the chemical industry, rubber industry and electroplating industry, and 2km away from the light pollution source such as the food manufacturer and leather plant. -
Page 49: Appendix F Mini Usb Console Driver Installation
Hardware Installation and Reference Guide Appendix F Mini USB Console Driver Installation Appendix F Mini USB Console Driver Installation The Mini USB Console driver can be downloaded on the official TI website (http://www.ti.com/). The driver is now supported only on 32-bit Windows XP, 64-bit Windows XP, 32-bit Window Vista, 64-bit Window Vista, 32-bit Windows 7, and 64-bit Windows 7. - Page 50 Hardware Installation and Reference Guide Appendix F Mini USB Console Driver Installation Step 3: Select the unpackage directory and click Install. Step 4: After the driver is installed, click Finish.
- Page 51 Hardware Installation and Reference Guide Appendix F Mini USB Console Driver Installation After the Mini USB Console driver is installed, you are able to perform commissioning on devices with Mini USB ports using Type-A male USB to male Mini USB cables. Right click Computer, choose Manage-Device Manager-Ports (COM &...
