CHARGE STATUS INDICATOR

The CHARGING and FULLY CHARGED LEDs will illuminate and flash in various patterns
to indicate the different stages of charging. See below for flash patterns.
Green LED
Red LED
Flashing GREEN LED: Charging
Solid GREEN LED: Charged
Flashing RED LED: Fault
Solid RED LED: Power on not connected

POLARITY PROTECTION

Prevents the output leads from sparking due to accidental reverse connection or short
circuit making the charger safer to use around batteries.

OVER TEMPERATURE PROTECTION

If the temperature within the charger rises too high, the charger will begin reducing the
power output. If still unsuccessful, the charger will shutdown until it cools down.
SWITCHMODE TECHNOLOGY
Using the latest technology in battery chargers, switchmode chargers convert 240VAC
power to 12VDC power using electronic components unlike traditional battery chargers
that rely on heavy transformers. This allows the charger to be lightweight and compact
without sacrificing on performance.
4
Soft Start 1 Soft Start 2
(Fast Flash) (Fast Flash)
Solid On: AC Power Connected
Flashing: Fault (see Faults and Errors on page 9)
Bulk Absorption
(Slow Flash) (Slow Flash)
Float
(Solid On)
