- Page 1 INSTRUCTIONS FOR INSTALLATION AND USE GES8MPU GAS RANGE WITH ELECTRIC OVEN FOR RESIDENTIAL AND PROFESSIONAL USE...
- Page 2 Officine Gullo...
-
Page 3: Table Of Contents
ELECTRIC CONNECTION .....................20 USER MANUAL INSTRUCTIONS FOR USE .....................22 LIGHTING AND ADJUSTING THE BURNERS ................22 TURNING ON AND ADJUSTING THE ELECTRIC OVEN .............22 CARE AND CLEANING INSTRUCTIONS .................23 WHAT TO DO IN THE EVENT OF A BREAKDOWN ..............24 Officine Gullo... -
Page 4: Warnings And Safety Instructions
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. • If you cannot reach your gas supplier, call the fire department. Installation and service must be performed by a qualified installer, service agency or the gas supplier. Officine Gullo... - Page 5 Use an extinguisher ONLY if: i) You know you have a Class ABC extinguisher, and you already know how to operate it. ii) The fire is small and contained in the area where it started. iii) The fire department is being called. iv) You can fight the fire with your back to an exit. Officine Gullo...
- Page 6 • Combustible items (paper, plastic, etc.) may ignite and metallic items may become hot and cause burns. DO NOT pour spirits over hot foods. DO NOT leave oven unsupervised when drying herbs, breads, mushrooms, etc; fire hazard. Officine Gullo...
- Page 7 • ALWAYS place oven racks in the desired positions while oven is cool. Slide oven rack out to add or remove food, using dry, sturdy potholders. ALWAYS avoid reaching into the oven to add or remove food. If a rack must be moved while hot, use a dry potholder. Officine Gullo...
- Page 8 NOT extend handles over adjacent surface burners. ALWAYS turn pan handles toward the side or back of the appliance, not out into the room where they are easily hit or reached by small children. • NEVER let a pan boil dry as this could damage the utensil and the appliance. Officine Gullo...
- Page 9 Before first use, wipe interior with soapy water and dry thoroughly. Then switch on the oven at the maximum temperature and operate for an hour. There may be some burn off and odors on first use of the appliance—this is normal. Officine Gullo...
-
Page 10: Installation Manual
Einspritzventil flamme Injecteur feux Injector cooking rings Inyector fuegos Regolazione aria Luftregelung Réglage d'air Air regulation Regulación aire 2. Air regulation 4. Thermocouple Candela accensione Zündkerze Bougie d'allumage Lighting spark plug Candela encendido Termocoppia Thermoelement Thermocouple Thermocouple Termopar Officine Gullo... -
Page 11: Electrical Scheme
The circuit where you wire your appliance to must be grounded and polarized. We recommend the circuit for your appliance be a non-GCFI dedicated line. Fig. C ELECTRICAL SCHEME TOP Electrical connection Push-button starting burner 3/4. Power-station starting burner Officine Gullo... - Page 12 Témoin blanc White light Luz indicadora blanca Spia verde grüne Kontroll-Leuchte Témoin vert Green light Luz indicadora verde Termostato sicurezza Sicherheits-thermostat Thermostat de sécurité Safety thermostat Termostato de seguridad Termostato Thermostat Thermostat Thermostat Termostato LIBR.ALLEG.CF70GE 230Vac 230Vac3 Officine Gullo 563035700.doc...
-
Page 13: Installation Instructions
INSTALLATION INSTRUCTIONS This appliance is manufactured by OFFICINE GULLO S.r.l Headquarters and factory 50012 Antella - Bagno a Ripoli (FI) Italy via della Torricella, 29. Tel. +39 055 6560324 In the US call 800 620 8490 Home page http:// www.officinegullo.com E-Mail: info@officinegullo.com... - Page 14 (NAT = natural gas; LP = LPG) NAT: set for natural gas LP: set for LPG 3) Insert the gas regulator, in the chosen side, in the hex cap. 4) Put the hex nut in place and screw it in. Officine Gullo...
-
Page 15: Gas Connections
AN OPEN FLAME TO CHECK FOR LEAKS. Such a procedure is dangerous, and it may not detect all the small leaks that a soapy solution will 15. Air shutter adjustments are preset at the factory. These adjustments may need to be redone and/or fine tuned by the installer. Officine Gullo... -
Page 16: Technical Electrical Data Table
Nr. Open ring Nr. Open ring Nr. Open ring 11,942 18,767 25,591 BTU/h BTU/h BTU/h BTU/h GES8MPU R1/2GM 75,067 80x70x90h 3/4GM(1007) The machine is supplied with pressure regulator separately (in 3/4 NPT F) TECHNICAL ELECTRICAL DATA TABLE Dimensions Max. Power supply... -
Page 17: Installation
All our appliances undergo careful testing: the type of gas, the operating pressure and the category are indicated on the data plate. NB: The year of the appliance manufacture is shown in item “N” on the data plate. The first two numbers (e.g. 08...) represent the year of manufacture. Officine Gullo... -
Page 18: Checking Heat Output
THIS APPLIANCE IS EQUIPPED WITH THE GAS TYPE AS PER YOUR ORDER - A conversion kit is provided with the range if it ever needs to be converted to a diferent type of gas supply (LPG or Natural Gas). Officine Gullo... -
Page 19: Adjustments In Main Burners
Main Injector size addjustment (Primary Aeration Burner Consumption Nominal/(Measured) (By-pass Screw Adjustment) (BTU/h) (mm) Adjustment) Values in mm (See note) Small 11,942 0.95 0.50 Fully closed Medium 18,767 1.10 0.60 Fully closed Large 25,591 1.35 0.75 Fully closed Officine Gullo... -
Page 20: Rules For Converting And Installing For Other Types Of Gas
The appliance may be supplied without the connection cable. In this case, the connection cable must have the following characteristics: it must be type H05RNF and must have an adequate section for the power of the appliance (see technical data table). Officine Gullo... - Page 21 IMPORTANT ! MAKE SURE TO ALWAYS DISCONNECT THE APPLIANCE FROM THE ELECTRICITY BEFORE WORKING ON IT. Picture 1E Picture 2E Officine Gullo...
-
Page 22: User Manual
Caution: when the oven is on, the door must be kept shut otherwise the knobs and protection sheet could get hot and be damaged. NEVER cover any slot, holes or passages in the oven bottom nor the ventilation grill on top of the range. Officine Gullo... -
Page 23: Care And Cleaning Instructions
Oxidation that may appear over time on the nickel plated brass surfaces is a normal characteristic of this living finish. Please follow the general cleaning guidelines to keep this finish close to its original hue and minimize the appearance of use. Officine Gullo... -
Page 24: What To Do In The Event Of A Breakdown
Leaving foods like citrus fruit juice, salt, vinegar, mustard, pickles and mayonnaise on your surface for prolonged periods can cause pitting and corrosion. WHAT TO DO IN THE EVENT OF A BREAKDOWN Turn off the gas shut off valve and notify your authorized service center or call our main line at 800 620 8490 Officine Gullo... - Page 25 Officine Gullo...
- Page 26 Officine Gullo...
- Page 27 Officine Gullo...
