- Page 1 INSTRUCTIONS FOR INSTALLATION AND USE TPS4GP - TPS8GP GAS COUP DE FEU FOR RESIDENTIAL AND PROFESSIONAL USE...
- Page 2 14. In case of failure or malfunction, turn the appliance off, close the gas supply valve and do not attempt to carry out any repairs, which must be done exclusively by an authorized service center. Request the use of original spare parts only. Failure to comply with the above recommendations may compromise the appliance’s safety. Officine Gullo...
-
Page 3: Table Of Contents
WHAT TO DO IN THE EVENT OF A BREAKDOWN ..............14 PROCEDURE TO FOLLOW IF THE APPLIANCE IS NOT GOING TO BE USED FOR SOME TIME ..14 MAINTENANCE (only for qualified personnel) ................14 INSTRUCTIONS FOR DISCHARGING GAS EMISSIONS ............14 Officine Gullo... -
Page 4: Installation Manual
INSTALLATION MANUAL Fig. A/1 TPS4GP 73 cm 70 cm 3 cm 4 cm E / G (1/2") (1/2") 20 cm 67 cm 40 cm E.Electrical Connection LEGEND G. Gas Connection Electric connection/Connessione lettrica G Gas connection/Connessione Gas 40 cm Officine Gullo... - Page 5 Fig. A/2 TPS8GP E.Electrical Connection E.Electrical Connection G. Gas Connection G. Gas Connection Officine Gullo...
- Page 6 Fig. B COUP DE FEU 1. Injector 2. Pilot Officine Gullo...
- Page 7 Fig. C TOP WIRING DIAGRAM Electrical connection Push-button starting burner 3/4. Power-station starting burner Officine Gullo...
-
Page 8: Declaration Of Compliance
DECLARATION OF COMPLIANCE This appliance is manufactured by OFFICINE GULLO S.r.l Headquarters and factory Via Della Torricella 29, Antella, Bagno a Ripoli 50012 Florence - Italy Tel. +39 055 65 60 3324 +39 055 62 18 07 officinegullo.com | info@officinegullo.com The manufacturer declares that the appliances are compliant with the prescriptions of the EEC norm 2009/142 for the gas part and with norm 2006/95/CE, 2004/108/CE for the electric part. -
Page 9: Installation
Take suitable measures to guarantee thermal insulation of the inflammable sides, such as, for example, the installation of protection against radiation. The appliances must be installed in a suitable manner, observing the safety standards. The small feet are adjustable to level the appliance. Officine Gullo... -
Page 10: Pipe For Gas Connection
Connection with natural gas H G20 The connection pressure for natural gas is 20 mbar. Check the plate, read the pressure and verify that the description of the nozzle installed corresponds to the one supplied by the manufacturer. Officine Gullo... -
Page 11: Checking Primary Air To The Main Burners And Pilot Nozzles
Adjust the minimum flame by turning the by-pass screw either to the right or to the left until heat output reaches 4 kW. The primary air of the all plate burner does not need adjusting. Attention: If liquid gas is used, the minimum flame adjustment screw must be screwed right down. Officine Gullo... -
Page 12: Checking Functioning
If the flame goes out you have to repeat the procedure. By turning the knob round to the position the burner is at maximum. By turning the knob round to the position the burner is at minimum. To switch off, move the knob back into position " 0". Officine Gullo... -
Page 13: Cleaning And Maintenance
Do not use abrasive pads or any other chemical products. Cleaning brushed steel surfaces All the brushed steel surfaces should be cleaned using degreasing products or products specifically designed to be used on steel and, where necessary, extra-fine steel wool or extra-thin sandpaper. Officine Gullo... -
Page 14: What To Do In The Event Of A Breakdown
Supplying the appliance with gas again must only be possible manually. NATURAL DISCHARGE NATURAL DISCHARGE FORCED DISCHARGE FORCED DISCHARGE Fig.1 Fig.1 Fig.2 Fig.2 1. Extractor hood 1. Extractor hood 1. Extractor hood 1. Extractor hood 2. Interlocking 2. Interlocking Officine Gullo... - Page 15 FORCED DISCHARGE Fig. 3 Fig. 4 1) Anti-wind (blow back) chimney 1. Extractor hood 2. Interlocking Type “B11” appliances are supplied upon request with chimney or chimney and anti-wind (blow back) device to be assembled and delivered separately. Officine Gullo...
- Page 16 international V 1.2 - 9.20 Tel. +39 055 656 0324 | info@officinegullo.com Via Della Torricella 29, Antella, Bagno a Ripoli - 50012 Florence - Italy OFFICINEGULLO.COM...
