- Page 1 GGS8P GGS12P GGPS8P GGPS12P GES8P GES12P GEPS8P GEPS12P RANGE WITH OVEN FOR RESIDENTIAL AND PROFESSIONAL USE INSTRUCTIONS for installation and use...
- Page 2 14. In case of failure or malfunction, turn the appliance off, close the gas supply valve and do not attempt to carry out any repairs, which must be done exclusively by an authorized service center. Request the use of original spare parts only. Failure to comply with the above recommendations may compromise the appliance’s safety Officine Gullo...
- Page 3 FIG.A A. Data plate B. Electrical Connection C. Gas Connection Officine Gullo...
- Page 4 Einspritzventil flamme Injecteur feux Injector cooking rings Inyector fuegos Regolazione aria Luftregelung Réglage d'air Air regulation Regulación aire 2. Air regulation 4. Thermocouple Candela accensione Zündkerze Bougie d'allumage Lighting spark plug Candela encendido Termocoppia Thermoelement Thermocouple Thermocouple Termopar Officine Gullo...
- Page 5 Candela accensione Zündkerze Bougie d'allumage Lighting spark plug Candela encendido Termocoppia Thermoelement Thermocouple Thermocouple Termopar 4. Pilot bracket Staffa pilota Bügel Leitflamme Bride veilleuse Pilot bracket Brida del piloto FIG. F (oven) FIG. J (FORNO, FOUR, BACKOFEN, OVEN, HORNO) Officine Gullo...
- Page 6 FIG. G Coup de feu Injector Pilot Officine Gullo...
- Page 7 FIG. H FIG. K Officine Gullo...
- Page 8 FIG. I ELECTRICAL SCHEME TOP 1. Electrical connection 2. Push-button starting burner 3/4. Power-station starting burner Officine Gullo...
- Page 9 FIG.L WIRING DIAGRAM STATIC OVEN GN2/1 Commutator Junction-box Element White light Green light Thermostat Safety thermostat Officine Gullo...
-
Page 10: Table Of Contents
WHAT TO DO IN THE EVENT OF A BREAKDOWN ......21 PROCEDURE TO FOLLOW IF THE APPLIANCE IS NOT ....21 GOING TO BE USED FOR SOME TIME ..........21 MAINTENANCE (only for qualified personnel) ......... 21 INSTRUCTIONS FOR DISCHARGING GAS EMISSIONS ....22 Officine Gullo... -
Page 11: Gas Technical Data Table
NOMINAL BURNER CAPACITY kW CAPACITY Dimensions Gas coupling MODEL ISO 7-1 Coup de Burner Burner Burner oven 3,5 kW 5,5 kW 7,5 kW 7,3 kW 7 kW GGS8P 80x70x90h 29,3 R3/4GM GES8P 80x70x90h R3/4GM GGS12P 120x70x90h 42,3 R3/4GM GES12P 120x70x90h R3/4GM GGPS8P 80x70x90h... -
Page 12: Declaration Of Compliance
All fire prevention codes shall be observed. a) General indications (Rules valid for GB only) - For all appliances: Gas safety Regulations, 1984; Health and safety at Work Act, 1974 Codes of Practice, BS 8173, 1982, The Building Officine Gullo... -
Page 13: Pipe For Gas Connection
N.B. The connection cable must have the following characteristics: it must be type H05RN-F and must have an adequate section for the power of the appliance (see tech- nical data table). Officine Gullo... -
Page 14: Equipotential
The pilot air is regulated when the appliance is tested and inspected for the gas it is set for. If you are going to change to a different type of gas, regulate the air by means of the adju- sting bush until the flame stops sputtering and becomes an intense blue colour. Officine Gullo... -
Page 15: Burner" Technical Data Table
0.772 m3 st./h Primary air h=mm Oven Burner max 11 kW- min. 3,5 kW Burner injector 1/100 mm Min. output adjustment 1/100 mm adjustable Pilot Injector 1x19 1x19 1x27 Consumption 0.859 kg/h 0.859 kg/h 1.164 m3 st./h Primary air h=mm Officine Gullo... -
Page 16: Rules For Converting And Installing Other Types Of Gas
Adjust the minimum flame by turning the by-pass screw either to the right or to the left until heat output reaches 4 kW. The primary air of the all plate burner does not need adjusting. Attention: If liquid gas is used, the minimum flame adjustment screw must be screwed right down. Officine Gullo... -
Page 17: Checking Functioning
Gas oven: the gas-cock, timer, thermocouples, burners and ignition plugs can be changed by accessing them inside the oven and/or by removing the bottom oven panel or control panel. Officine Gullo... -
Page 18: Instructions For Use
If the flame goes out you have to repeat the procedure. By turning the knob round to the position the burner is at maximum. By turning the knob round to the position the burner is at minimum. To switch off, move the knob back into position " 0". Officine Gullo... - Page 19 Top + bottom heating element Bottom heating element Top heating element Caution: when the oven is on the door must be kept shut otherwise the knobs and protection sheet could get hot and be damaged. Officine Gullo...
-
Page 20: Cleaning And Maintenance
All the chromium-plated surfaces should be cleaned, where necessary, with a soft, possibly micro-fiber cloth, combined with metal polishing products, if required. Do not use abrasive pads. Officine Gullo... -
Page 21: What To Do In The Event Of A Breakdown
Turn off the gas tap and clean the appliance as specified above. MAINTENANCE (only for qualified personnel) Any kind of maintenance must only be done by qualified personnel. Before carrying out maintenance,remove the plug or switch off the switch above the appliance. Officine Gullo... -
Page 22: Instructions For Discharging Gas Emissions
4.3 of the UNI-CIG norm 8723. Supplying the appliance with gas again must only be possible manually. NATURAL DISCHARGE FORCED DISCHARGE Fig.1 Fig.2 1. Extractor hood 1. Extractor hood 2. Interlocking Officine Gullo... - Page 23 Officine Gullo...
- Page 24 INTERNATIONAL V 1.0 - 10. 17 OFFICINE GULLO S.R.L.: via della Torricella 29, 50012 Antella - Bagno a Ripoli (FI) Tel. +39 055 6560324 / 621807 - Fax: + 39 055 620670 - info@officinegullo.com WWW.OFFICINEGULLO.COM...
