- Page 1 Solution Ultima 880 Quick Reference Guide ISSUE 1.51...
- Page 2 Notice of Liability While every precaution has been taken in the preparation of this document, neither Bosch Security Systems Pty Limited nor any of its official representatives shall have any liability to any person or entity with respect to any liability, loss or damage caused or alleged to be caused directly or indirectly by the information contained in this book.
-
Page 3: Programming Using A Codepad
1234# Exit Installer’s Programming Mode 960# Step To Next Location Step Back One Location Program New Data Into Location Data + * (Data = 0 – 15) Jump To Another Location Location No. + # Bosch Security Systems Pty Limited... -
Page 4: Codepad Indicators
Quick Reference Guide Solution Ultima 880 Codepad Indicators Data Zone 1 Zone 2 Zone 3 Zone 4 Zone 5 Zone 6 Zone 7 Zone 8 MAINS Value Indicator Indicator Indicator Indicator Indicator Indicator Indicator Indicator Indicator Programming Option Bits You will notice option bits throughout the quick reference guide. This allows you to program any combination of the four different options in the one location by adding the options together. -
Page 5: Isolating Zones
Press and hold the 0 key until two beeps are want to delete followed by the # key. heard (Only if no alarm). Press the * key to delete the RF device. Enter your code followed by the # key. [eg. 2580 + #]. Bosch Security Systems Pty Limited... - Page 6 Quick Reference Guide Solution Ultima 880 Add RF Keyfob Set First Test Report Enter the Master Code followed by 1 and the Enter the Installer Code followed by 1 and the # key [eg. 2580 + 1 + #]. key [eg. 1234 + 1 + #].
- Page 7 Press and hold the 6 key until two beeps are Press 2 followed by the # key. heard. Enter the Call Forward Off sequence. Latching Outputs (Reset) Press the # key to exit. Press and hold the 7 key until two beeps are heard. Bosch Security Systems Pty Limited...
- Page 8 Location 000 – 015 Phone Number 1 - Receiver 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 Location 016 – 031 Phone Number 2 – Receiver 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 Location 032 Handshake Tone 1 = HI-LO Handshake (Contact ID)
- Page 9 Arm/Disarm + Open/Close Reports + Code Required To Isolate Master Code + Arm/Disarm Master Code + Arm/Disarm + Open/Close Reports Master Code + Arm/Disarm + Code Required To Isolate Master Code + Arm/Disarm + Code Required To Isolate + Open/Close Reports Bosch Security Systems Pty Limited...
-
Page 10: Day Alarm Zones
Location 265 Day Alarm Zones 1 = Zone 1 4 = Zone 3 2 = Zone 2 8 = Zone 4 Location 266 EOL Resistor Value 0 = No EOL 6 = 4K7 12 = Reserved 1 = 1K 7 = 5K6 13 = Reserved 2 = 1K5 8 = 6K8... - Page 11 Momentary Arm and Disarm In AWAY Mode Momentary Arm In AWAY Mode Momentary Disarm From AWAY Mode Or STAY Mode Momentary Arm and Disarm In STAY Mode Momentary Arm In STAY Mode Momentary Disarm From STAY Mode Bosch Security Systems Pty Limited...
- Page 12 Location 323 Swinger Shutdown Count For Siren 0 = Unlimited / 1 - 15 = Number Of Times Siren Operate Till Lockout Location 324 Swinger Shutdown Count For Dialler 0 = Unlimited / 1 - 15 = Number Of Times Dialler Operate Till Lockout Location 325 - 326 Location 325 = Zone Tamper Report Zone Status –...
- Page 13 0 = No Codepad Alarm Reports Allowed 1 = Report To Receiver 1 2 = Report To Receiver 2 4 = Report To Both Receiver 1 & Receiver 2 8 = Report To Receiver 2 Only If Receiver 1 Fails Bosch Security Systems Pty Limited...
-
Page 14: Event Codes
Location 380 - 409 Outputs Location 380 381 384 385 Location 386 387 390 391 Output 1 Output 2 1 14 Default = Horn Event Polarity Time Time Base Default = Fire Alarm Event Polarity Time Time Base Speaker Code Base Multiplier With Verification... - Page 15 ‘OFF’ time. The ‘OFF’ time is the time base x the multiplier (eg. If you want the output to pulse one (1) second ‘ON’ and five (5) seconds ‘OFF’, you would program time base as one (1) and the multiplier as five (5)). Bosch Security Systems Pty Limited...
- Page 16 Location 435 = (0 = No Beeps / 15 = Loudest Beeps) Location 436 System Options 1 1 = BOSCH Smart Lockout Allowed 2 = Horn Speaker Monitor 4 = Strobe Indication For Radio Arm/Disarm 8 = Assign Button 4 On Transmitter To Operate STAY Mode 1...
- Page 17 Location 459 = Zone 6 LED – Area 2 Codepad 0 0 0 0 0 0 0 0 Location 460 = Zone 7 LED – Area 2 Codepad Location 461 = Zone 8 LED – Area 2 Codepad Bosch Security Systems Pty Limited...
- Page 18 Location 462 - 477 User Code Area Assignment 0 = User Code Not Assigned 1 = User Code Assigned To Area 1 2 = User Code Assigned To Area 2 3 = User Code Assigned To Both Area 1 and Area 2 Location User Code 1 User Code 2...
- Page 19 RF signal from a remote RF device. RF Keyfob Operations For Solution Ultima Series Control Panels Figure 2: RF3332 - 2 Button RF Keyfob Figure 3: RF3332 - 2 Button RF Keyfob Bosch Security Systems Pty Limited...
-
Page 20: Wiring Diagram For Keyswitch Zone
Connections For Split EOL Resistors For 8 Burglary Zones Figure 4: Split EOL Wiring Diagram (Location 266 = 15) Figure 5: Split EOL Wiring Diagram With Tamper (Location 266 = 14) Connections For Split EOL Resistors For 8 Zone Operation Using N/O Contacts Figure 6: Split EOL Wiring Diagrams Using N/O Contacts Wiring Diagram For Keyswitch Zone Figure 7: Wiring Diagram For Keyswitch Zone... -
Page 21: Wiring Diagram
Quick Reference Guide Solution Ultima 880 Wiring Diagram Figure 8: Solution Ultima Series Wiring Diagram Bosch Security Systems Pty Limited... -
Page 22: Component Overlay
Component Overlay Figure 9: Solution Ultima Series Component Overlay... -
Page 23: Codepad Connections For Partitioning - Examples
ON position. The following locations for Output 1 will need to be programmed. [LOCATION 380 = 6, 381 = 1 Figure 11: Connections For Two CP-5 Eight Zone Area Addressable (CP500A) Codepad Bosch Security Systems Pty Limited...
