ADJUSTMENT GUIDE

ADJUSTING THE PEDALS
The Pedal Straps (No. 48) can be adjusted to
the user's own foot/shoe size.
Pull the Pedal Straps (No.28/29) to adjust the
degree of tightness.
ADJUSTING THE RESISTANCE
To adjust the tension level, turn the Adjustment
Knob (C) on the cylinder to the desired level.
The tension levels range from Level 1 to Level
12, with Level 1 being the lowest resistance. The
number pointing to the Regulator (C) by the
Arrow (B) is the current resistance value of the
hydraulic cylinder.
NOTE: During operation, please do not adjust
the resistance of the hydraulic cylinder to avoid
injury and damage to the machine.
