- Page 1 3460HATV 20 cu ft WELDED STEEL ATV CART READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT 3190460 - REV C 07/15...
-
Page 2: Safety Rules
Safety Rules This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Read and understand all safety rules and operating instructions before using this ATV/UTV attachment. -
Page 3: Carton Contents
Carton Contents 8 (x1) 2 (x1) 6 (x1) 5 (x4) 15 (x1) 4 (x1) 1 (x1) 7 (x1) 3 (x1) 16 (x2) 11 (x2) 12 (x2) 9 (x1) 18 (x1) 17 (x1) 13 (x2) 20 (x2) 10 (x1) 14 (x1) 19 (x19) 21 (x1) TOOLS REQUIRED FOR ASSEMBLY:... - Page 4 Assembly Instructions Attach front support and backing plate to body securely with hardware as shown. Attach axle holder plates to body loosely with hardware as shown. Attach latch and hitch bracket to drawbar with hardware as shown. Secure latch spring between latch and drawbar post.
- Page 5 Assembly Instructions Insert axle into undercarriage halfway as shown. Slide axle completely through undercarriage; be sure to catch the drawbar when sliding the axle. Align drawbar with the front support and press down firmly to latch. Attach wheels to axle with spacers and washers, secure with cotter pins as shown.
- Page 6 Assembly Instructions Attach tailgate to body as shown. No hardware is required, tailgate should move freely up or down. Attach hitch bracket to drawbar with hardware as shown. * BE SURE TO TIGHTEN ALL HARDWARE AT THIS TIME Install hitch pin and hairpin to secure to attachment vehicle.
- Page 7 Operating Instructions Before Using Dump Cart: Apply lithium grease to wheels using grease gun until grease can be seen squeezing out from both sides of the wheel. Check tire pressure and inflate to 24 psi if needed. Read all Safety Rules found on page 1. How to Use Dump Cart: Attach Dump Cart to your ATV or UTV.
-
Page 8: Warranty
This warranty applies only while this product is in use in the United States. In the space below record the purchase date of your Dump Cart. 3460HATV Model Number Purchase Date Keep this Owner's Manual and your receipt in a safe place for future reference. -
Page 9: Repair Parts
Repair Parts REPLACEMENT PARTS ORDERING OHIO STEEL INDUSTRIES 1-800-652-2321... - Page 10 Notes...
- Page 11 Designed And Tested In Columbus, Ohio Manufactured In The U.S.A. From Domestic And Imported Components MODEL # 3460HATV 2575 Ferris Road Columbus, OH 43224 (800) 652-2321 www.OHIOSTEEL.com (800) 652-2321...
