Summary of Contents for OHIOSTEEL 3460SD-ATV
- Page 1 3460SD-ATV 20 cu ft WELDED STEEL ATV CART READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT 6004215 - REV B 08/18...
-
Page 2: Safety Rules
Safety Rules This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Read and understand all safety rules and operating instructions before using this ATV/UTV attachment. -
Page 3: Carton Contents
Carton Contents 2 (x1) 4 (x1) 1 (x1) 3 (x1) 7 (x1) 37 (x1) 9 (x2) 8 (x1) 6 (x2) 12 (x1) 5 (x2) 15 (x2) 38 (x4) 14 (x2) 16 (x4) 10 (x8) 11 (x14) 19 (x1) 13 (x3) 17 (x2) 18 (x2) TOOLS REQUIRED FOR ASSEMBLY:... - Page 4 Assembly Instructions Attach undercarriage to body securely with hardware as shown. Attach front support to body securely with hardware as shown. Align holes in swivel clevis and undercarriage and install pin as shown. Secure pin on both ends with hairpins.
- Page 5 Assembly Instructions Press down on drawbar until it locks into place. Insert stub axles into undercarriage and secure with pins as shown. Slide washers and wheels onto stub axles as shown and install cotter pins. Bend legs of cotter pin to secure.
- Page 6 Assembly Instructions Attach tailgate to body as shown. No hardware is required, tailgate should move freely up or down. Attach ball hitch to drawbar with spacers and hardware as shown. Install hitch pin and hairpin to secure High Speed Safety Clevis.
-
Page 7: Periodic Maintenance
Operating Instructions Before Using Dump Cart: Apply lithium grease to wheels using grease gun until grease can be seen squeezing out from both sides of the wheel. Check tire pressure and inflate to 24 psi if needed. Read all Safety Rules found on page 1. How to Use Dump Cart: Attach Dump Cart to your ATV or UTV. -
Page 8: Warranty
This warranty applies only while this product is in use in the United States. In the space below record the purchase date of your Dump Cart. 3460SD-ATV Model Number Purchase Date Keep this Owner's Manual and your receipt in a safe place for future reference. -
Page 9: Exploded View
EXPLODED VIEW ITEM PART NO DESCRIPTION QTY ITEM PART NO DESCRIPTION 6004183 BODY, WELDED 3460 6000369 SHOULDER BOLT, 1/2" X 3/8" 6004193 UNDERCARRIAGE 3000720 WASHER, 3/8" USS 6004221 FRONT SUPPORT 300061 HEX NUT, 3/8-16 C-LOCK 6004216 DRAWBAR ASSEMBLY (incl. 20-32) 6000324 BEARING 6000523 AXLE, STUB 6000370 HEX BOLT, 3/8-16 X 3-1/2"... -
Page 10: Repair Kits
6004220 WELDED DRAWBAR Before you call… Please email our customer service team at cs@ohiosteel.com with: 1. A description of the issue you are having 2. Photos of the issue that include an overall view and detailed view from multiple angles 3. - Page 11 Notes...
- Page 12 Designed And Tested In Columbus, Ohio Manufactured In The U.S.A. From Domestic And Imported Components MODEL # 3460SD-ATV 2575 Ferris Road Columbus, OH 43224 (800) 652-2321 www.OHIOSTEEL.com (800) 652-2321...
