- Page 1 4048P-HYB 15 cu ft POLY SWIVEL HYBRID DUMP CART U.S. Patent No. 8,496,298 READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT 6000407 - REV J 8/19...
-
Page 2: Safety Rules
Safety Rules This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Read and understand all safety rules and operating instructions before using this tractor/ATV/UTV attachment. -
Page 3: Warranty
Paint that is worn or faded due to normal use or exposure. To arrange for product repair visit ohiosteel.com/customer-support and fill out the warranty repair form. You can also call 1-800-652-2321, ext. 212 to speak to our Customer Service Team This warranty gives you specific legal rights, and you may also have other rights which may vary from state to state. -
Page 4: Carton Contents
Carton Contents 2 (x1) 3 (x1) 1 (x1) 4 (x2) 5 (x2) (x1) 23 (x2) (x1) 25 (x4) 26 (x8) 27 (x12) 24 (x2) 31 (x2) 30 (x2) 28 (x12) 32 (x2) 33 (x1) 29 (x4) 34 (x2) 35 (x1) TOOLS REQUIRED FOR ASSEMBLY: •... - Page 5 Assembly Instructions Hold Poly Body (1) on side as shown. Insert Hex Bolts (25 &26) as shown. Flip Poly Body (1) to expose bolts. Tape Tape Tape TIP: Bolt heads can be secured with tape to aid in assembly. Install Undercarriage (2) over top of Hex Bolts. Install Lockwasher (27) and tighten Hex Nuts (28) onto Hex Bolts.
- Page 6 Assembly Instructions Attach Front Support (3) to Poly Body (1). Install Lockwasher (27) and tighten Hex Nuts (28) onto Hex Bolts. Insert Stub Axles (4) into Undercarriage (2) and secure with Clevis Pins (31) and Hairpin Cotters (32). Slide Washers (29) and Wheels (5) onto Stub Axles (4). Install Cotter Pins(30).
- Page 7 Assembly Instructions Align holes in Swivel Clevis and Undercarriage and install Clevis Pin (33) as shown. Secure Pin with Hairpin (34). Depress Foot Pedal (11), insert Front Support (3) into Drawbar Assembly. When Drawbar is locked in place, flip cart upright onto wheels. Insert preassembled hybrid hitch assembly into Drawbar.
- Page 8 Operating Instructions Before Using Dump Cart: Apply lithium grease to wheels using grease gun until grease can be seen squeezing out from both sides of the wheel. Check tire pressure and inflate to 24 psi if needed. Read all Safety Rules found on page 1. How to Use Dump Cart: Attach Dump Cart to your tractor, ATV, or UTV as shown below.
- Page 9 Do-It-Yourself Accessories 35.13 31.63 USE 1/2" PLYWOOD 35.25 USE STANDARD 2 X 4 34.00 13.00 45.00 13.00 13.00 USE NOMINAL GRADE C 1 X 3...
-
Page 10: Repair Parts
HAIRPIN COTTER, 1-3/16" 3/8" FLANGED BUSHING CLEVIS PIN, 1/2" X 2" SPRING, LATCH HAIRPIN COTTER, 2-5/16" SPRING WASHER, 1/2" HITCH PIN SHOULDER BOLT, 1/2" 1" BEARING RETAINER 6000818 3/8"-16 X 3-1/2" HEX BOLT 1" ROLLER BEARING ohiosteel.com/partstore OHIO STEEL INDUSTRIES 1-800-652-2321... - Page 12 Designed And Tested In Columbus, Ohio Manufactured In The U.S.A. From Domestic And Imported Components MODEL # 4048P-HYB 2575 Ferris Road Columbus, OH 43224 (800) 652-2321 www.ohiosteel.com (800) 652-2321...
