- Page 1 4048P-SD 12.5 cu ft POLY SWIVEL DUMP CART U.S. Patent No. 8,496,298 READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT 6003622 - REV A 11/15...
-
Page 2: Safety Rules
Safety Rules This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Read and understand all safety rules and operating instructions before using this tractor attachment. -
Page 3: Tools Required For Assembly
Carton Contents 1 (x1) 2 (x1) 19 (x1) 20 (x1) 3 (x1) 21 (x1) 22 (x2) 27 (x1) 24 (x2) 23 (x4) 25 (x12) 26 (x12) 28 (x3) TOOLS REQUIRED FOR ASSEMBLY: • 1/2" Wrench or Socket • Grease Gun... - Page 4 Assembly Instructions Attach Undercarriage to Poly Body and tighten hardware. Attach Front Support to Poly Body and tighten hardware. Insert Axle into Undercarriage halfway as shown. Center Spacer inside Swivel Clevis and align with Axle.
- Page 5 Assembly Instructions Slide Axle completely through Undercarriage; Swivel Clevis and Spacer must be captured by Axle. Align Drawbar with Front Support and press down to latch. Slide Washers, Spacers and Wheels onto Axle and secure with Hairpins as shown. Install Hitch Pin as shown.
- Page 6 Operating Instructions Before Using Dump Cart: Apply grease to wheels using grease gun until grease can be seen squeezing out from both sides of the wheel. Check tire pressure and inflate to 28 psi if needed. Read all Safety Rules found on page 1. How to Use Dump Cart: Attach Dump Cart to your tractor using the supplied hitch pin.
- Page 7 Do-It-Yourself Accessories 8 " 13" 8 " USE 1/2" PLYWOOD 4 " USE STANDARD 2 X 4 34" 13" 45" 16" 13" 13" USE NOMINAL GRADE C 1 X 3...
-
Page 8: Warranty
United States. In the space below record the purchase date of your Dump Cart. Model Number 4048P-SD Purchase Date Keep this Owner's Manual and your receipt in a safe place for future reference. After the two year warranty period all replacement parts may be ordered by calling 1-800-652-2321 . - Page 9 Repair Parts REPLACEMENT PARTS ORDERING OHIO STEEL INDUSTRIES 1-800-652-2321...
- Page 10 Designed And Tested In Columbus, Ohio Manufactured In The U.S.A. From Domestic And Imported Components MODEL # 4048P-SD 2575 Ferris Road Columbus, OH 43224 (800) 652-2321 www.OHIOSTEEL.com (800) 652-2321...
