- Page 1 3040P 10 cu ft POLY DUMP CART READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT 6000181 - REV E 3/11...
-
Page 2: Safety Rules
Safety Rules This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Read and understand all safety rules and operating instructions before using this tractor attachment. -
Page 3: Tools Required For Assembly
Carton Contents 8 (x2) 2 (x2) 1 (x1) 3 (x4) 4 (x1) 7 (x2) 6 (x1) 5 (x1) 9 (x1) 11 (x2) 25 (x1) 23 (x1) 22 (x2) 12 (x2) 21 (x12) 24 (x3) 19 (x32) 20 (x34) 10 (x4) TOOLS REQUIRED FOR ASSEMBLY: •... - Page 4 Assembly Instructions Attach Front Support and Latch Angle loosely to Brace Supports as shown using supplied hardware. Attach Undercarriage Axle Supports loosely to body with hardware as shown. * NO SCREW Attach Front Support Assembly loosely to body with hardware as shown.
- Page 5 Assembly Instructions Attach two axle holders to the axle supports as shown using the supplied hardware * NOTE: LOOSELY TIGHTEN BOLTS AT THIS TIME Attach latch angle to drawbar assembly with supplied hardware as shown Insert axle into undercarriage halfway as shown. Attach spacer, drawbar assembly, and spacer...
- Page 6 Assembly Instructions Slide axle completely through undercarriage. Align drawbar with the front support and pull handle to latch. Attach washers and spacers as shown. * NOTE: TIGHTEN ALL HARDWARE AT THIS TIME Slide wheels and washers onto axle and secure with hairpins as shown. * NOTE: MAKE SURE VALVE STEM IS FACING OUT...
- Page 7 Operating Instructions Before Using Dump Cart: Check tire pressure and inflate to 30 psi if needed. Read all Safety Rules found on page 1. How to Use Dump Cart: Attach Dump Cart to your tractor using the supplied hitch pin. Do not exceed 325 pounds when loading material into the cart body.
-
Page 8: Warranty
United States. In the space below record the purchase date of your Dump Cart. Model Number 3040P Purchase Date Keep this Owner's Manual and your receipt in a safe place for future reference. After the two year warranty period all replacement parts may be ordered by calling 1-800-652-2321 . -
Page 9: Repair Parts
Repair Parts REPLACEMENT PARTS ORDERING OHIO STEEL INDUSTRIES 1-800-652-2321... - Page 10 Designed And Tested In Columbus, Ohio Manufactured In The U.S.A. From Domestic And Imported Components MODEL # 3040P 2575 Ferris Road Columbus, OH 43224 (800) 652-2321 www.OHIOSTEEL.com (800) 652-2321...
