8 SCPI Command Program
OUTPut:RAMP:BMEMTime <n | MINimum | MAXimum>
Set the ramp ON time for memory B.
Range
Unit
Format example
Initial value
Query
Remarks
OUTPut:RAMP:CMEMTime <n | MINimum | MAXimum>
Set the ramp ON time for memory A.
Range
Unit
Format example
Initial value
Query
Remarks
OUTPut:RAMP:MODe <CVCC | CV | CC>
Set the ramp operation mode.
Range
Format example
Initial value
Query
Remarks
8-5

Range for Voltage Setting and Current Setting

Rated voltage [V]
under 10.00
10.00 to under 100.0
0.0 to under 1000
over 1000
✽ Max = Rated voltage of each model x Rated current x Coefficient
Matsusada Precision PVCE/PVCEJ series
0.0s, 1.0s to 35999999.9s | 0.0m, 0.1m to 599999.9m | 0.0h, 0.1h to 9999.9h
sec | min | hr
OUTP:RAMP:BMEMT 12.3s
OUTP:RAMP:BMEM 0.0s
In response to "OUTP:RAMP:BMEM?", it returns the set ramp ON time for memory B.
・ The time from 0.1s to 0.9s cannot be set.
・ The setting cannot be switched while the output is turned on.
・ Only one type of unit is allowed.
0.0s, 1.0s to 35999999.9s | 0.0m, 0.1m to 599999.9m | 0.0h, 0.1h to 9999.9h
sec | min | hr
OUTP:RAMP:CMEMT 12.3s
OUTP:RAMP:CMEM 0.0s
In response to "OUTP:RAMP:CMEM?", it returns the set ramp ON time for memory C.
・ The time from 0.1s to 0.9s cannot be set.
・ The setting cannot be switched while the output is turned on.
・ Only one type of unit is allowed.
CVCC | CV | CC
OUTP:RAMP:MOD CV
OUTP:RAMP:MOD CVCC
In response to "OUTP:RAMP:MOD?", it returns the set operation mode.
・ The setting cannot be switched while the output is turned on.
Min [V]
Max [V]
0.000 9.999
0.00 99.99
0.0 999.9
20 9999
✽
Rated current [A]
under 10.00
10.00 to under 100.0
0.0 to under 1000
over 1000
58
✽
Min [A]
Max [A]
0.000 9.999
0.00 99.99
0.0 999.9
20 9999
