Summary of Contents for real living CAL-602004
- Page 2 GENERAL BEST PRACTICES FOR ASSEMBLY: WARNINGS: To prevent serious injury or death, this product is equipped with a wall anchoring system. Before this product can be used, the wall anchoring system must be installed as directed in the assembly instructions.
-
Page 3: Care And Cleaning
CARE AND CLEANING: Maximum width of The television: 50 INCH MAINTENANCE:... -
Page 4: Parts List
PARTS LIST Top panel Left side panel Right side panel Bottom panel Left stand panel Right stand panel Cross panel Left door Right door Back panel Block wood Upper/Under decorative panel Insert stop Left/Right decorative panel Bottom Frame Baffle Shelf panel Door stop Upper back panel... -
Page 5: Hardware List
HARDWARE LIST Cam-bolts Cam-locks Handle Handle Φ7*5/8" Φ8*5/8" Bolts Screws Dowel Allen wrench Φ6*1" Cam-tool Screws Shelf supports Hinges Φ8*1-1/2" Φ11*1-1/4" Fireplace insert Plastic tie Flat head screws Bolts Hook Anchor Spring washer Flat washer Φ7*5/8" Screws... - Page 6 STEP 1 Insert 2 Cam-Bolts (A) into Left Stand panel (5) as shown and fully tighten. Align the cam-Bolts (A) in Left Stand panel (5) with the holes in Cross panel (7) and Slide into place. Secure in place with 2 Cam-Lock (B) using Cam-Tool (I).
- Page 7 STEP 2 Attach Bottom Frame Baffle (15) to Bottom panel (4) with 5 Bolt (P), 5 Spring washer (S), 5 Flat washer (T) as shown. Carefully turn the Bottom panel (4) upright and insert 4 Cam-Bolt (A) as shown and fully tighten.
- Page 8 STEP 3 Insert 4 Cam-Bolt (A) into Bottom panel (4) as shown and fully tighten. Align the holes in Left Side panel (2) with the Cam-Bolts in Bottom panel (4) and slide into place as shown. Secure Left Side panel (2) to Bottom panel with 2 Cam-Lock (B) using Cam-Tool (I).
- Page 9 STEP 4 Insert 4 Cam-Bolt (A) into the holes of Top panel (1) as shown and fully tighten. Align the Cam-Bolts (A) in Top panel 1 with the holes in the Left and Right Stand panels (5/6) and slide into place as shown. Secure Top panel (1) to the Left and Right Stand panels (5/6) with 4 Cam-Lock (B) using Cam-Tool (I).
- Page 10 STEP 5 Slide the 4 Dowel (G) into the holes on the Left/Right decorative panels (14) and align with the holes on the Under/Upper Decorative panels (12). Secure the panels together with 4 screws (J). Place the assembled Frame into the cabinet and secure it to Cross panel (7) and Bottom panel with 4 Screw (J).
- Page 11 STEP 6 Attach 4 Hinges (L) to the Left door (8) and the Right door (9) with 8 Screws (F). Attach 2 Handles (C) and 2 Handles (D) to the Left and Right Doors with 6 Bolts (E). Attach the Hinges (L) of Left door (8) to Side panel (2) with 8 Screws (F).
- Page 12 STEP 7 Place 4 Shelf panel (16) onto the Shelf supports as shown. Attach Upper Back panel (18) to the back of the fireplace with 10 Screws (U) as shown. Attach 2 Hook (Q) to Top panel (1) with 4 Screw (U). Attach 2 Block wood (11) to Bottom panel (4) with 4 Screw (J) as shown.
- Page 13 STEP 8 Place the insert from the back. Attach Insert Stop (13) to Left and Right Stand panel (5/6) with 2 Bolt (P), 2 Spring washer (S), 2 Flat washer (T) as shown.
- Page 14 STEP 9 Once assembly is complete, Place the fireplace in the desired position along the wall. With a pencil, lightly mark the location where Hook (Q) meets the wall. Remove the fireplace away from the wall. Place one of the remaining Hook (Q) just under the marked location and mark the hole locations with the pencil.
- Page 15 TOP PANEL MAXIMUM LOAD 20 POUNDS MAXIMUM LOAD 66 POUNDS LOWER SHELVES MAXIMUM LOAD 35 POUNDS BOTTOM PANEL MAXIMUM LOAD 35 POUNDS MANFACTURER: CHIN-SHU WOODEN LTD. MODEL:CAL-602004 DISTRIBUTION: Big Lots Stores, Inc. ADDRESS: P,O. Box28523;Columbus, OH 43228-0523 COUNTRY OF ORIGIN: Vietnam...
