- Page 1 INSTALLATION & MAINTENANCE MANUAL LWALL1A / LWALL2A / LWALL3A...
- Page 2 These instructions should be used to aid installation of the following products: LWALL1A / LWALL2A / LWALL3A SAFETY • This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671) and current Building Regulations.
- Page 3 INSTALLATION Note - If this luminaire is being used in conjunction with an external PIR or sensor, please confirm with the manufacturer of the sensors that they are compatible with LED luminaires • Provide power to the required point of installation (refer to BS7671 for correct cabling methods).
- Page 4 Connect the luminaire to the mains supply ensuring the correct polarity is observed: Live (brown), • Connect the luminaire to the mains supply ensuring the correct polarity is observed: Live Earth (green/yellow), Neutral (blue) (see Fig. 2) (brown), Earth (green/yellow), Neutral (blue) (see Fig. 2) g.
- Page 5 WARNING This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance testing. Irreparable damage will occur if this instruction is not followed. This product is not suitable for installation in or near a coastal or marine environment. GENERAL The light source of this luminaire is not replaceable;...
- Page 6 INTERNATIONAL CONTACT DETAILS INTERNATIONAL CONTACT DETAILS ~35 °C ML Accessories Limited LU5 4LT www.mlaccessories.co.uk AVOCT21_V2...
