- Page 1 INSTALLATION & MAINTENANCE MANUAL BATCxx...
- Page 2 GENERAL INSTRUCTIONS INSTRUCTIONS – BATCxx These instructions should be read carefully and retained after installation by the end user for future reference and maintenance. ons should be read carefully and retained after installation by the end user for future reference and These instructions should be used to aid installation of the following products: BATC4 / BATC5 / BATC5H / BATC6 / BATC6H ons should be used to aid installation of the following products:...
- Page 3 PART CODE DISTANCE (MM) BATC4 BATC5 / BATC5H 1265 BATC6 / BATC6H 1529 Ensuring correct polarity is observed, carefully wire as shown in Fig. 2 • • Ensuring correct polarity is observed, carefully wire as shown in Fig. 2 Live (brown) Earth (green/yellow) Neutral (blue) Fig.
- Page 4 GENERAL The LED lamps fitted in this product are non-replaceable. The unit should be recycled in the correct manner when it reaches the end of its life. Check local authorities for where facilities exist. Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may damage the product.
