- Page 1 INSTALLATION & MAINTENANCE MANUAL LEDxxx / LEDTxxx...
- Page 2 GENERAL INSTRUCTIONS These instructions should be read carefully and retained after installation by the end user for future reference and maintenance. These instructions should be used to aid installation of the following products: LED3WB / LED3WCW / LED3WWW / LED5WB / LED5WCW / LED5WWW / LED11WB / LED11WCW / LED11WWW LEDT3WCW / LEDT3WWW / LEDT5WCW / LEDT5WWW / LEDT11WCW / LEDT11WWW SAFETY •...
- Page 3 Ensuring correct polarity is observed, connect the 230V mains supply to the primary side of the 24V constant voltage driver, Live (Brown), Neutral (Blue) (LEDAD36 pictured, not supplied) (see Fig. 2) Fig. 2 Fig. 2 Connect the secondary side of the driver to the luminaire Switch on and check for correct operation •...
- Page 4 LED8SPLIT – an 8-way splitter for use with the flat and triangular ranges of striplights • Connect the secondary side of the driver to the splitter • Connect the luminaires into the sides of the splitter - up to a maximum of 8 LEDFCON / LEDTCON –...
