- Page 1 INSTALLATION & MAINTENANCE MANUAL BATM2 / BATM4 / BATM5 / BATM6 / MODEMKIT / MODMWS...
-
Page 2: General Instructions
These instructions should be used to aid installation of the following products: BATM2 / BATM4 / BATM5 / BATM6 / MODEMKIT / MODMWS SAFETY • This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671) and current Building Regulations. -
Page 3: Installation
Mark the location of the fixing holes and drill the holes ensuring not to infringe with any gas/water pipes or electrical cables. The fitting can also be mounted over conduit boxes: for distance between fixing centres please see below: Distance (mm) Product Code BATM2 BATM4... - Page 4 The fitting can also be mounted over conduit boxes: for distance betwee ntres please see below: Distance (mm) Product Code BATM2 BATM4 BATM5 BATM6 • Fix the base to a suitable solid surface using the screws provided. • Ensuring correct polarity is observed, carefully wire as shown in Fig. 2 •...
- Page 5 Fig. 2 MODEMKIT MODEMKIT • Install by using the clips to secure them in place • Luminaire with emergency mode and no sensor connected, connect the connectors Install by using the clips to secure them in place • Luminaire with emergency mode and no sensor connected, connect the connectors labelled A from •...
-
Page 6: Dip Switch Settings
DIP SWITCH SETTINGS Detection area Detection area Hold Time Hold Time 5sec 5sec Detection area Hold Time 100% 100% 30sec 30sec 5sec 100% 1min 1min 30sec 3min 3min 1min 5min 5min 3min 10min 10min 5min 20min 20min 10min 30min 30min 20min This is the time period the lamp remains at 100% 30min... - Page 7 MODEMKIT & MODMWS • Install the MODEMKIT and MODMWS by using the clips to secure them in place • Luminaire with emergency mode and sensor connected, connect the connectors labelled A from the terminal block to A(EM) from the emergency module, connector labelled A(S) from sensor to connector labelled B(EM) from emergency module, connector labelled B from the driver to B(S) from sensor, connector labelled C(LED) from emergency module to C LEDs and connectors labelled D(LED) from...
- Page 8 WARNING This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance testing. Irreparable damage will occur if this instruction is not followed. This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance testing.
-
Page 9: Warranty
WARRANTY This product has a warranty of 5 years (including battery) from date of purchase. Failure to install this product in accordance with the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch code will invalidate the warranty. If this product should fail within its warranty period, it should be returned to the place of purchase for a free of charge replacement. - Page 10 TEST RECORD SHEET SIGNED DATE INITIAL COMMISSIONING 3 HOUR TEST FIRST YEAR SECOND YEAR THIRD YEAR FOURTH YEAR FIFTH YEAR MONTH TEST SIGNED DATE SIGNED DATE SIGNED DATE SIGNED DATE SIGNED DATE FUNCTIONAL FUNCTIONAL FUNCTIONAL FUNCTIONAL FUNCTIONAL FUNCTIONAL FUNCTIONAL FUNCTIONAL FUNCTIONAL FUNCTIONAL FUNCTIONAL...
- Page 11 Manufacturers Declaration of Conformity For ML Accessories (Knightsbridge) Electrical products in accordance with UKCA marking ML Accessories Ltd. declare that all products have been designed, manufactured, and tested in accordance with the requirements of the relevant legislation UKCA marking legislation UK SI 2016 No.
- Page 12 Manufacturers Declaration of Conformity For ML Accessories (Knightsbridge) Electrical products in accordance with CE marking ML Accessories Ltd. Declare that all products have been designed, manufactured, and tested in accordance with the requirements of the relevant legislation CE marking legislation...
- Page 13 SUPPLIED BY: (UK) MANUFACTURER ML ACCESSORIES LTD, UNIT E CHILTERN PARK, BOSCOMBE ROAD, DUNSTABLE LU5 4LT, WWW.MLACCESSORIES.CO.UK (EU) AUTHORISED REPRESENTATIVE SLV LIGHTING GROUP, DAIMLERSTRASSE 21-23, 52531 ÜBACH-PALENBERG, GERMANY EMAIL: EPREL@GROUP.SLV.COM MADE IN CHINA -20~ 230V °C 50Hz JBAPR24_V1...
