Safety, Operation, Maintenance
038570 Engine, LT15 19HP Dieselrev.C
Used with
LT15D19
WARNING! Read and understand this
!
manual before using this machine.
D19 Engine
& Parts Manual
obsolete as of rev. E6.07
Safety is our #1 concern!
Form #1355

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D19 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Wood-mizer D19

  • Page 1 D19 Engine Safety, Operation, Maintenance & Parts Manual 038570 Engine, LT15 19HP Dieselrev.C Used with LT15D19 obsolete as of rev. E6.07 Safety is our #1 concern! Form #1355 WARNING! Read and understand this manual before using this machine.
  • Page 2 For more information go to www.P65Warnings.ca.gov/wood. Active Patents assigned to Wood-Mizer, LLC Wood-Mizer, LLC has received patents that protect our inventions which are a result of a dedication to research, innovation, development, and design. Learn more at: woodmizer.com/patents ©2023 Wood-Mizer LLC...
  • Page 3: Table Of Contents

    Table of Contents Section-Page SECTION 1 ABOUT THIS MANUAL SECTION 2 OPERATION Starting the Engine........................2-1 SECTION 3 MAINTENANCE Safety ............................3-1 Cooling System ..........................3-1 Air Filter & Pre-Cleaner ......................3-1 Fuel Filter............................. 3-2 RPM Adjustments ........................3-2 Miscellaneous Maintenance......................3-2 SECTION 4 REPLACEMENT PARTS Fuel Tank .............................
  • Page 4: Section 1 About This Manual

    About This Manual SECTION 1 ABOUT THIS MANUAL This manual is provided as a supplement to the equipment manufacturer’s manuals. This manual provides information specific to the use of this equipment on the Wood-Mizer sawmill. Refer to the sawmill ®...
  • Page 5: Section 2 Operation

    Operation Starting the Engine SECTION 2 OPERATION Starting the Engine DANGER! Ensure the blade is disengaged and all persons are out of the path of the blade before starting. Failure to do so will result in death or serious injury. DANGER! Operate your engine only in well ventilated areas.
  • Page 6: Section 3 Maintenance

    Maintenance Safety SECTION 3 MAINTENANCE Refer to the manufacturer’s manual for maintenance intervals and procedures unless otherwise instructed in this manual. Fol- low the manufacturer’s recommendations for dusty conditions. NOTICE This manual only provides information about additional procedures or procedures to be performed at different time intervals than found in the manufacturer's manuals.
  • Page 7: Fuel Filter

    Maintenance Fuel Filter Fuel Filter Replace the fuel filter every 100 hours of operation or as required for engine performance. RPM Adjustments WARNING! Remove the blade before performing any engine service. Failure to do so may result in serious injury. Check the RPM with a tachometer every 200 hours of operation.
  • Page 8: Section 4 Replacement Parts

    Replacement Parts Fuel Tank SECTION 4 REPLACEMENT PARTS Fuel Tank LT15 Rev. E8.08+ LT15W Rev. A1.08+ 150245B PART # DESCRIPTION COMMENTS QTY. 074828 TANK ASSEMBLY, 5 GALLON DIESEL 103802 Weldment, Fuel Tank Tray 103867 Cover, Fuel Tank 103928 Tank, 5 Gallon Low Pro Diesel 061257 Cap, Fuel Tank Diesel 080185BE 061255...
  • Page 9: Fuel Tank

    Replacement Parts Fuel Tank Fuel Tank LT15 Rev. E6.05 - E8.07 LT15W Rev. A1.00 -A1.07 150137-4C PART # DESCRIPTION COMMENTS QTY. A12132 TANK ASSEMBLY, 5 GALLON DIESEL P12166 Tank, 5 Gallon Fuel Available in assemblies only. P12172 Pickup, 9" Fuel 061257 Cap, Fuel Tank Diesel 080298AE 015583...
  • Page 10: Engine Assembly

    014209 Filter, Fuel F05015-7 Screw, #10-24 x 1/2” Self-Tapping Screw used instead of P09900 clamp. 038590 Deflector, 1 1/4” ID Exhaust D19 047742 Sheave, 3V5.6 x 2-SH 038432 Bushing, SH x 1 1/8” S04124 Key, 1/4” x 1 11/16” 049399...
  • Page 11 Nut, 3/8-16 Hex Nylon Lock 038572 Plate, 1/4” Spacer D19 038573 Spacer, 13/32” ID x 1 1/4” OD x 1/4” 038574 Bracket, LT15 D19 Filter Mount 048237 Support Weldment, Drive Belt F05007-118 Bolt, 3/8-16 x 3/4” Hex Head Grade 5 F05010-19...
  • Page 12: Throttle/Clutch Assembly

    Replacement Parts Throttle/Clutch Assembly Throttle/Clutch Assembly 150137-2E PART # DESCRIPTION COMMENTS QTY. P04211 KNOB, 5/8-11 BALL HANDLE, LT15 CLUTCH 016487 Clutch Handle 016487 modified Rev. E6.01 to eliminate possible pinch point with feed rope pulley with saw head at certain heights.
  • Page 13 Replacement Parts Throttle/Clutch Assembly PART # DESCRIPTION COMMENTS QTY. WASHER, 1/2” SPLIT LOCK F05011-9 F05010-31 NUT, 1/2-13 JAM 034608 PIVOT WELDMENT, CLUTCH/BRAKE P737 BUSHING, 1” X 1 1/4” X 3/4” FLG BRONZE 065874 BRAKE/CLUTCH ASSEMBLY, LT15 Replaces Brake/Clutch Assem- bly 034603 to improve durability (Rev.
