D24 Engine
Safety, Operation, Maintenance
& Parts Manual
LT35
LT35HD
Safety is our #1 concern!
* The D24 engine was first available with the
LT35 rev A6.08 and the LT35HD rev A6.10
rev. A6.08* - A6.12
rev. A6.10* - A6.15
Form #2208

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Wood-mizer D24

  • Page 1 Safety, Operation, Maintenance & Parts Manual LT35 rev. A6.08* - A6.12 LT35HD rev. A6.10* - A6.15 Safety is our #1 concern! Form #2208 * The D24 engine was first available with the LT35 rev A6.08 and the LT35HD rev A6.10...
  • Page 2 Active Patents assigned to Wood-Mizer, LLC Wood-Mizer, LLC has received patents that protect our inventions which are a result of a dedication to research, innovation, development, and design. Learn more at: woodmizer.com/patents ©2021 Wood-Mizer LLC Printed in the United States of America, all rights reserved. No part of this manual may be reproduced in any form by...
  • Page 3: Table Of Contents

    Table of Contents Section-Page About This Manual.................1-1 SECTION 1 OPERATION Starting The Engine................1-1 SECTION 2 MAINTENANCE Safety......................2-1 Air Filter & Pre-Cleaner .................2-1 Fuel Filter ....................2-2 Battery ....................2-2 Alternator Belt ..................2-2 SECTION 3 REPLACEMENT PARTS Fuel Tank....................3-1 Engine Mounts ..................3-2 Engine Service Parts ................3-3 Engine Base ..................3-5 Drive Shaft and Flywheel Cover ............3-6...
  • Page 4: About This Manual

    This manual is provided as a supplement to the equipment manufacturer’s manuals. This manual provides sawmill. Refer to the sawmill opera- information specific to the use of this equipment on the Wood-Mizer ® tor’s manual and manufacturer's manual before attempting to operate this equipment.
  • Page 5: Maintenance

    Maintenance Safety SECTION 2 MAINTENANCE Refer to the manufacturer’s manual for maintenance intervals and procedures unless otherwise instructed in this manual. Follow the manufacturer’s recommendations for dusty conditions. IMPORTANT! This manual only provides information about additional procedures or pro- cedures to be performed at different time intervals than found in the manufacturer's man- uals.
  • Page 6: Fuel Filter

    Maintenance Fuel Filter Clean the air filter (air cleaner element) and pre-cleaner (element wrapper) every eight hours of operation. See the engine manual for further instructions. Replace the air filter (cleaner) every 200 hours of operation. Replace the pre-cleaner (element wrapper) every 2000 hours of operation. 2000 Fuel Filter Replace the fuel filter every 100 hours of operation or as required for engine performance.
  • Page 7 Maintenance Alternator Belt See Figure 2-1. Loosen bolt to pivot alternator clockwise and tighten belt 3H1174-6 FIG. 2-1 LT35 D24 Maintenance WM doc 3/5/21...
  • Page 8: Replacement Parts

    REPLACEMENT PARTS Fuel Tank 3H1174-1B DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. TRAY ASSEMBLY, LT35 D24 DIESEL TANK 079084 Weldment, Fuel Tank Tray 103810 Cover, Fuel Tank 103867 Tank, 5 Gallon Low Pro EPA Fuel 103928...
  • Page 9: Engine Mounts

    Replacement Parts Engine Mounts Engine Mounts TD-D24-01 DESCRIPTION (♦ Indicates Parts Available in Assemblies Only) PART # QTY. Bolt, 3/8-16x3 1/2 HH Gr5 F05004-123 Washer, Motor Mount 018751 Bushing, Kubota Rubber Mount (two pieces) 018734 Washer, 3/32x3/4 Stepped 074822 Bolt, M10-1.50x20mm HH FT 8.8...
  • Page 10: Engine Service Parts

    Belt, Yanmar Fan #25132-003500 061204 Switch, Temp WM Installed/Plug on wires #121250-44901 044655 Alternator, 105A 12V Modified w/Harness #20-146-C2 079280 Solenoid, Fuel Shut Off D24 #119233-77932 061211 Gasket, Water Temp Switch D24 #124465-44950 061212 Starter Assembly, D24 #119515-77010 061214 Relay, Pre-Heat Crank Fuel D24 #119650-77911...
  • Page 11 Dipstick, Yanmar #119025-34800 061203 Pipe, Yanmar Fuel Return #119D00-59540 061205 Radiator Kit, Yanmar #119515-44500 061206 Bottle Assy, Yanmar #121468-44520 061207 Pump, Fuel Injection D24 #719D25-51310 061306 Filter Assembly, Fuel 119833-55621 061295 Filter, Fuel Yanmar #119810-55650 061099 Replacement Parts WM doc 3/5/21...
  • Page 12: Engine Base

    1 2 3 16 17 TD-D24-04 DESCRIPTION (♦ Indicates Parts Available in Assemblies Only) PART # QTY. ASSY, D24 YANMAR TIER4 FINAL BASE ENGINE 122336 Weldment, D24 Radiator Fan Guard 079282 Washer, 5/16 Split Lock F05011-13 Washer, 1/4 SAE Flat F05011-11 Bolt, M6-1.0x45 HH Class 8.8...
  • Page 13: Drive Shaft And Flywheel Cover

    PART # QTY. Bolt, M8x1.25x25 HH FT F05004-40 Washer, 5/16 Split Lock F05011-13 Washer, 5/16 Star ET F05011-33 Shaft, 1-7/16 Yanmar D24 Short Stub 074969 Screw, M8x1.25x25mm Flat Socket C/S BO CL-10.9 F05021-30 Bushing, SHx1 7/16 016535 Sheave, 3V5.6x2-SH 047742...
  • Page 14: Control Panel And Throttle Cable

    DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. Bolt, #10-24x1 Unslotted HH F05004-156 Clamp, Throttle Cable 079082 Plate, D24 Throttle Cable Mount 074795 Washer, #10 SAE Flat F05011-18 Nut, 10-24 Hex Nylock-> F05010-160 Throttle Fitting, Swivel 048904 Nut, M8-1.25 Hex Nylock...
  • Page 15 Bolt, #10-32x1/2 HH F05004-60 Washer, #10 Split Lock F05011-20 Washer, #10 SAE Flat F05011-18 Bolt, 1/4-20x1 1/4 HH FT Cap F05005-3 Plate, D24 Key Switch/Control Mount 074797 Washer, 1/4 SAE Flat F05011-11 Nut, 1/4-20 Nylock F05010-69 Replacement Parts WM doc 3/5/21...
  • Page 16: Fuel Pump Assembly

    3H1174-5 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. Sensor Assembly, LT35D24 Fuel Pump/Pressure 079066 Plate, D24 Yanmar Fuel Pump Mount 079065 Clamp, 3/16 Wire 13/32 Mounting Hole 079083 Bolt, 1/4-20x1 Hex Head Grade 5 F05005-101 Bolt, 5/16-18x1 Hex Head...
  • Page 17: Throttle Assembly

    Replacement Parts Throttle Assembly Throttle Assembly 3H1089-4D DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. BLOCK WELDMENT, LINKAGE CLUTCH/BRAKE 065574 PIN, 3/16” X 1 1/4” ROLL F05012-16 BUSHING, 5/8” ID X 7/8” OD X 1 1/4” LONG FL BRONZE 016486 SHAFT, LT28 THROTTLE 049340...
  • Page 18 Replacement Parts Throttle Assembly Nut, 1/2-13 Half Nylon Lock F05010-127 BRAKE/CLUTCH ASSEMBLY 065874 Arm Weldment, Clutch/Brake 065873 Bolt, 3/8-16 x 2 Hex Head Grade 5 F05007-124 Nut, 3/8-16 Hex Nyl Lock F05010-10 Washer, 3/8” Flat SAE F05011-3 Nut, 3/8-16 Swaged F05010-25 Spring, Idler Arm LT15/D/E/G 034810...
