Safety, Operation, Maintenance
007334 Engine Module, LT15D17
Used with:
LT15D18 (OBS)
LT15D17
LT15D17W
D18 engines were re-designated D17 on
11/12/2013 per ECN 19807 to match the actual
rating of the engine.
WARNING! Read and understand this
!
manual before using this machine.
D17/18 Engine
& Parts Manual
Safety is our #1 concern!
April 2010
rev. E6.05 - E7.00
rev. E7.01- E8.13
rev. A1.00 - A1.14
revA-F
Form #1631
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wood-mizer D17
Summary of Contents for Wood-mizer D17
- Page 1 E6.05 - E7.00 LT15D17 rev. E7.01- E8.13 LT15D17W rev. A1.00 - A1.14 D18 engines were re-designated D17 on 11/12/2013 per ECN 19807 to match the actual rating of the engine. WARNING! Read and understand this manual before using this machine.
- Page 2 For more information go to www.P65Warnings.ca.gov/wood. Active Patents assigned to Wood-Mizer, LLC Wood-Mizer, LLC has received patents that protect our inventions which are a result of a dedication to research, innovation, development, and design. Learn more at: woodmizer.com/patents ©2022 Wood-Mizer LLC...
-
Page 3: Table Of Contents
Table of Contents Section-Page SECTION 1 ABOUT THIS MANUAL SECTION 2 OPERATION Starting The Engine ................2-1 SECTION 3 MAINTENANCE Safety ..................... 3-1 Battery....................3-1 Air Filter & Pre-Cleaner ................ 3-1 Fuel Filter....................3-2 Miscellaneous Maintenance..............3-2 SECTION 4 REPLACEMENT PARTS Fuel Tank .................... -
Page 4: Section 1 About This Manual
SECTION 1 ABOUT THIS MANUAL This manual is provided as a supplement to the equipment manufacturer’s manuals. This manual provides information specific to the use of this equipment on the Wood-Mizer sawmill. Refer to the sawmill oper- ® ator’s manual and manufacturer's manual before attempting to operate this equipment. -
Page 5: Section 2 Operation
Operation Starting The Engine SECTION 2 OPERATION Starting The Engine DANGER! Ensure the blade is disengaged and all persons are out of the path of the blade before starting. Failure to do so will result in death or serious injury. DANGER! Operate your engine only in well ventilated areas. -
Page 6: Section 3 Maintenance
Maintenance Safety SECTION 3 MAINTENANCE Refer to the manufacturer’s manual for maintenance intervals and procedures unless otherwise instructed in this manual. Fol- low the manufacturer’s recommendations for dusty conditions. This manual only provides information about additional procedures or proce- NOTICE dures to be performed at different time intervals than found in the manufacturer's manu- als. -
Page 7: Fuel Filter
Maintenance Fuel Filter Clean the air filter (air cleaner element) and pre-cleaner (element wrapper) every eight hours of operation. Replace the air filter (cleaner) every 200 hours of operation. Replace the pre-cleaner (element wrapper) every 2000 hours of operation. See the engine manual for further instructions. Fuel Filter Replace the fuel filter every 100 hours of operation or as required for engine performance. -
Page 8: Section 4 Replacement Parts
Replacement Parts Fuel Tank SECTION 4 REPLACEMENT PARTS Fuel Tank LT15Rev. E8.08+ LT15WRev. A1.08+ 150245B DESCRIPTION (♦ Indicates Parts Available in Assemblies Only) PART # QTY. TANK ASSEMBLY, 5 GALLON DIESEL 074828 Weldment, Fuel Tank Tray 103802 Cover, Fuel Tank 103867 Tank, 5 Gallon Low Pro Diesel 103928... -
Page 9: Lt15Rev. E6.05 - E8.07
Replacement Parts Fuel Tank Fuel Tank LT15Rev. E6.05 - E8.07 LT15WRev. A1.00 -A1.07 150137-4C DESCRIPTION (♦ Indicates Parts Available in Assemblies Only) PART # QTY. TANK ASSEMBLY, 5 GALLON DIESEL A12132 Tank, 5 Gallon Fuel P12166 Pickup, 9" Fuel P12172 Cap, 3/5 Gallon Fuel Tank P09683... -
Page 10: Engine Assembly
Replacement Parts Engine Assembly Engine Assembly 150174-4 DESCRIPTION (♦ Indicates Parts Available in Assemblies Only) PART # QTY. Engine Assembly, LT15 18HP Diesel 007333 Engine, 18HP Kohler Diesel Model KDW702 007332 Filter Assembly, Kohler #ED0037004550-S 007401 Filter, Kohler Secondary Air #ED0021751250-S 007613 Filter, Kohler Primary Air #ED0021751240-S 007408... - Page 11 Nut, 5/16-18 Nylok Hex F05010-58 Washer, 5/16 Split Lock F05011-13 Washer, 5/16 SAE Flat F05011-17 panel, front D17 yanmar 074947 065408 replaces 014277 Kohler 14V 45A #ED0011573600-S Alternator and 065409 replaces 014212 Kohler Fan #ED0024403080-S Belt. Replacement Parts WM doc 2/21/22...
-
Page 12: Throttle/Clutch Assembly
Replacement Parts Throttle/Clutch Assembly Throttle/Clutch Assembly 150174-2F 30 29 DESCRIPTION (♦ Indicates Parts Available in Assemblies Only) PART # QTY. KNOB, 5/8-11 BALL P04211 HANDLE, LT15 CLUTCH 062313 SCREW, 3/8-16 X 3/8” SOCKET HEAD CUP PT SET F05007-68 ACTUATOR WELDMENT, THROTTLE LT15D&G 034815 LINKAGE, THROTTLE LT15D&G 034818... - Page 13 Replacement Parts Throttle/Clutch Assembly DESCRIPTION (♦ Indicates Parts Available in Assemblies Only) PART # QTY. Arm Weldment, Clutch/Brake LT15 065873 Bolt, 3/8-16 x 2” Hex Head Gr5 F05007-124 Nut, 3/8-16 Hex Nylon Lock F05010-10 Block, LT15 Brake 016488 Screw, 10-24 x 1” Socket Head F05004-2 Nut, #10-24 Keps F05010-14...
