Product Introduction
3.2

Basic Features

3.2.1

Features

The box has advanced technology, high reliability and convenient control functions,
as shown below:
•
Interact with inverter
•
According to the interactive information, judge and control the
running state of the battery system
BMS related control processing
•
Realize the corresponding fault identification and processing
•
•
Ensure the safe operation of the battery system.
•
Secondary protection by hardware
•
IP65 protection level
•
Safe and reliable
•
Small occupied area
•
Wall mounting
3.2.2 Certifications
Safety
EMC
3.3

Technical Data

Model
Dimension (W/H/D)(in/mm)
Dimension of Packing (W/H/D)(in/mm)
Net Weight (lbs/kg)
Recommend charge/discharge current [A]
Maximum Charge/Discharge Current (A)
Overvoltage Category (OVC)
Protective Class
8
IEC 62477-1, IEC 61439-1, IEC 61439-2
IEC 61000-6-1/2/3/4
BMS Parallel Box-II G2
14.48*13.15*6.04/368*334*153.5
17.32*15.63*10.12/440*397*257
19.12/8.7
25
35
II
I
Environment Requirement
Input/Output voltage Range (V)
Environment
Standard Power (kW)
Maximum Power (kW)
Altitude (ft/m)
Pollution Degree
Noise Level
Operating Temperature
Ingress Protection
System one Nominal Operating Total capacity
voltage [V] voltage [V]
[kWh]
(T-BAT-SYS-HV-5.8)
T-BAT S 5.8 G2
115.2 110-131
T-BAT S 11.5 G2 230.4 200-262
345.6 300-393
T-BAT S 17.3 G2
T-BAT S 23.0 G2 460.8
400-524
T-BAT P 5.8 G2 115.2
100-131
T-BAT P 11.5 G2 230.4 200-262
T-BAT P 17.3 G2 345.6 300-393
T-BAT P 23.0 G2 460.8 400-524
Nominal
System two Operating Total capacity
voltage [V] voltage [V]
(T-BAT-SYS-HV-3.0) [kWh]
T-BAT S 3.0 G2 102.4
90-116
204.8
T-BAT S 6.0 G2
180-232
T-BAT S 9.0 G2 307.2
270-348
T-BAT S 12.0 G2 409.6
360-464
T-BAT P 3.0 G2 102.4
90-116
T-BAT P 6.0 G2 204.8
180-232
307.2
T-BAT P 9.0 G2
270-348
409.6
T-BAT P 12.0 G2
360-464
Product Introduction
70-550
Outdoor
11.5
16.1
≤ 6561.68/2000
PD 3
<30dB
T-BAT-SYS-HV-3.0:
-30°C~55°C (with heating function)
-10°C~55°C (no heating function)
T-BAT-SYS-HV-5.8:
0°C ~ 55°C (no heating function)
I I P65
Nominal Max power
Usable capacity
power [kW]
[kW]
[kWh]
5.8 5.1 2.8
11.5 10.3 5.7
17.3 15.5
8.6 12.0
23.0
20.7 11.5 16.1
11.5 10.3 2.8
23.0 20.7 5.7
34.6 31.1 8.6
12.0
46.1 41.4 11.5
16.1
Usable capacity Nominal Max power
power [kW] [kW]
[kWh]
2.7 2.5
3.1
5.1
6.1 5.5
7.6
8.2
9.2
11.0 10.2 12.2
12.3
5.5 2.5
6.1
11.0 5.1
12.3
16.5 7.6
18.4
10.2
24.6 22.1 12.2
4.0
8.0
4.0
8.0
3.0
6.1
9.2
3.0
6.1
9.2
9
