Parts List - Linear Technology DC1784A Demo Manual

DEMO MANUAL DC1784A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 6 C2, C3, C4, C31, C32, C33
3 9 C5, C6, C7, C19, C20, C21, C25,
C27, C29
4 4 C8, C13, C14, C15
5 1 C9
6 3 C10, C11, C12
7 3 D1, D2, D3
8 3 L1, L2, L3
9 1 L4
10 3 M1, M3, M5
11 3 M2, M4, M6
12 1 R1
13 3 R2, R3, R4
14 3 R5, R6, R7
15 3 R8, R9, R10
16 3 R11, R12, R13
17 3 R14, R15, R16
18 1 U1
Optional Electrical Components
1 0 C16, C17, C18, C22, C23, C24
2 0 C26, C28, C30, C34, C35, C36
3 1 C37
4 3 D4, D5, D6
5 3 R17, R18, R19
6 3 R20, R21, R22
7 3 R23, R24, R25
8 1 R26
9 1 R27
10 1 R28
11 1 R29
12 1 R30
13 0 R31 to R34, R46
14 0 R35 to R45
Hardware
1 7 E2, E10, E11, E12, E16, E17, E18 TESTPOINT, TURRET 0.094"
2 20 E4 to E9, E13 to E15, E19 to E29
3 2 J1, J2
6
PART DESCRIPTION
Cap., X7R, 1µF, 50V, 10%, 0805
Cap., X7R, 4.7µF, 50V, 10%, 1210
Cap., X7S, 4.7µF, 100V, 20%, 1210
Cap., X7R, 0.1µF, 10V, 10%, 0603
Cap., X5R, 10µF, 10V, 20%, 0603
Cap., X7R, 6800pF, 25V, 10%, 0402
DIODE, PDS360, POWERDI-5
IND, 10µH, HC9-100-R
IND., 47µH, SD SERIES, IND-SD25
Mosfet, N-Channel, BSC039N06NS, PWRPAK SO-8
Mosfet, P-Channel, SI7113DN, PWRPAK1212-8
RES., CHIP, 47.5k, 1/16W, 1%, 0402
RES., CHIP, 0.25Ω, 1W, 1%, 2010
RES., CHIP, 3.9k, 1%, 0402
RES., CHIP, 23.2k, 1/16W, 1%, 0402
RES., CHIP, 0.008Ω, 1W, 1%, 2010
RES., CHIP, 1M, 1/10W, 1%, 0603
IC, LT3797EUKG QFN(52)(UKG)-7mm × 8mm
CAP., OPT 0402
CAP., OPT 1210
Cap., ALUM, 33µF, 50V, 6.3 × 7.7
DIODE, ES1B, 150V/1A, SMA
RES., CHIP, 1M, 1/16W, 1%, 0402
RES., CHIP, 140k, 1/16W, 1%, 0402
RES., CHIP, 100k, 1/10W, 1%, 0603
RES., CHIP, 100k, 1/16W, 1% , 0402
RES., CHIP, 105k, 1/16W, 1% , 0402
RES., CHIP, 0Ω, 0402
RES., CHIP, 0Ω, 1/4W, 1% , 1206
RES., CHIP, 0Ω, 1/10W, 1%, 0603
RES., OPT, 0402
RES., OPT, 0603
TESTPOINT, TURRET 0.064"
CONNECTOR, BANANA JACK
MANUFACTURER/PART NUMBER
MURATA, GRM21BR71H105KA12L
MURATA, GRM32ER71H475KA88L
TDK C3225X7S2A475M
AVX, 0603ZC104KAT2A
SAMSUNG CL10A106MP8NNNC
AVX, 04023C682KAT2A
DIODES/ZETEX, PDS360-13
COILTRONICS, HC9-100-R
COILTRONICS, SD25-470-R
INFINEON, BSC039N06NS
VISHAY, SI7113DN-T1-GE3
VISHAY, CRCW040247K5FKED
IRC, LRC-LR2010LF-01-R250-F
VISHAY, CRCW04023K90FKED
VISHAY, CRCW040223K2FKED
SEI, CSRF2010FT8L00
VISHAY, CRCW06031M00FKEA
LINEAR TECH.CORP. LT3797EUKG#PBF
OPT
OPT
PANASONIC, EEHZA1H330XP
DIODES/ZETEX, ES1B-13-F
VISHAY, CRCW04021M00FKED
VISHAY, CRCW0402140KFKED
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW0402100KFKED
VISHAY, CRCW0402105KFKED
VISHAY, CRCW04020000Z0ED
VISHAY, CRCW12060000Z0EA
VISHAY, CRCW06030000Z0EA
OPT
OPT
MILLMAX, 2501-2-00-80-00-00-07-0
MILL-MAX, 2308-2-00-80-00-00-07-0
KEYSTONE, 575-4
dc1784af
