3Com U.S. Robotics 56K Winmodem Manual page 14

I I I I W W W W
NSTALLING THE NSTALLING THE NSTALLING THE NSTALLING THE
1.
Turn off your computer and unplug it
from the electrical outlet.
2.
Unplug any peripheral devices (printer,
monitor, keyboard, mouse, etc.) from the
computer.
3.
Remove the cover of the computer.Refer
to your computer manufacturer's
manual, if you need instructions.
Your modem is designed as an ISA card
4.

or a PCI card. Hold the modem so that
the gold connectors are pointing at the
floor and the speaker and other
components (speaker, processor, etc.)are
facing you.
10
® ® ® ®
W W W W 95, W W W W 95, 95, 95,
INMODEM WITH INMODEM WITH INMODEM WITH INMODEM WITH INDOWS INDOWS INDOWS INDOWS
98, 98, 98, 98, W W W W NT 4.0 NT 4.0 NT 4.0 NT 4.0
INDOWS INDOWS INDOWS INDOWS AND AND AND AND INDOWS INDOWS INDOWS INDOWS
•
If the silver bracket is on the right,
you have an ISA card.
•
If the silver bracket is on the left, you
have a PCI card.
