VSO output resettable fuse
5VO output voltage
5VO output current
USB1 port output current
USB2 + USB_INTERNAL port output current
EXP port output voltage
EXP port output current
RASPBERRY PI COMPATIBILITY
Raspberry platform compatibility
COMMUNICATION PORTS
Serial communication ports
Baud Rates on COMM ports
ESD-Protection Voltage on RS-232 TX/RX
ESD-Protection Voltage on RS-485 A/B
Surge protection on RS-485 A/B
Fail safe feature on RS-485
CAN interface
ESD-Protection Voltage on CANH, CANL
Transient Voltage protection on CANH, CANL
USB ports
Ethernet Port
69
1.1 A
4.7 V (no load)
4.6 V (10 Ohm load)
500 mA (Max)
500 mA (Max)
500 mA (Max)
5 V
500 mA (Max)
Raspberry Pi Compute Module 1
Raspberry Pi Compute Module 3
Raspberry Pi Compute Module 3 Lite
Raspberry Pi Compute Module 3+ 8GB
Raspberry Pi Compute Module 3+ 16GB
Raspberry Pi Compute Module 3+ 32GB
Raspberry Pi Compute Module 3+ Lite
Raspberry Pi Compute Module 4S 8GB
Raspberry Pi Compute Module 4S 16GB
Raspberry Pi Compute Module 4S 32GB
Raspberry Pi Compute Module 4S Lite
RS-485 Half-Duplex with automatic data direction
management
RS-232 Full-Duplex
1200 to 115200
±15 kV human body model
±8 kV contact discharge
±15 kV human body model
±8 kV contact discharge
Surge protection up to ±500 V / 2 Ohms 1.2/50 μs;
600 W peak pulse power capability at 10/1000 μs
waveform
Yes
8 Mbps (Max. CAN-FD)
±14 kV human body model
±8 kV contact discharge
-150 V to +100 V (waveforms of the applied
transients in accordance with ISO-7637, Part 1, test
pulses 1, 2, 3a and 3b)
USB 2.0 Type A
10/100 Mbps
