- Page 1 Strato Pi Base User Guide August 2019 Revision 015 SPBB21X Strato Pi Base board SPMB21X Strato Pi Base server with Raspberry Pi 3 Model B SPMB21XP Strato Pi Base server with Raspberry Pi 3 Model B+ ...
-
Page 2: Table Of Contents
Safety information Qualified personnel Hazard levels Safety instructions General safety instructions Battery Introduction Features Usage and connections Hardware Installation Strato Pi Base board Strato Pi Base server Replacing the RTC backup battery Terminal block Power supply Dedicated GPIO pins Software installation and configuration Installing the Strato Pi utility on Raspbian Installing the Real Time Clock software Testing the Real Time Clock... - Page 3 CANADA AUSTRALIA / NEW ZEALAND Compliance information for Raspberry Pi 3 Model B CANADA Compliance information for Raspberry Pi 3 Model B+ CANADA Strato Pi Base User Guide...
- Page 4 The product information on the web site or materials is subject to change without notice. Please download and read the Sfera Labs Terms and Conditions document available at: http://www.sferalabs.cc Strato and Sfera Labs are trademarks of Sfera Labs S.r.l. Other brands and names may be claimed as the property of others.
-
Page 5: Safety Information
Safety information Carefully and fully read this user guide before installation and retain it for future reference. Qualified personnel The product described in this manual must be operated only by personnel qualified for the specific task and installation environment, in accordance with all relevant documentation and safety instructions. -
Page 6: Safety Instructions
Safety instructions General safety instructions Protect the unit against moisture, dirt and any kind of damage during transport, storage and operation. Do not operate the unit outside the specified technical data. Never open the housing. If not otherwise specified, install in closed housing (e.g. distribution cabinet). - Page 7 WARNING Improper handling of lithium batteries can result in an explosion of the batteries and/or release of harmful substances. Worn-out or defective batteries can compromise the function of this product. Replace the RTC lithium battery before it is completely discharged. The lithium battery must be replaced only with an identical battery.
-
Page 8: Introduction
Introduction Strato Pi Base enhances the Raspberry Pi Model B version 2 and 3 computers with several hardware features to make it suitable for use in professional applications where reliability and service continuity are key requirements. Strato Pi Base is available as a bare board or fully assembled unit including a Raspberry Pi 3 Model B or B+ in a standard DIN-rail case. -
Page 9: Features
Features Strato Pi Base board and server: ✓ 9-28Vdc power supply, with surge and reverse polarity protection, and 1.1A resettable fuse ✓ up to 3.1A max current to the 5V Raspberry Pi power supply input pins (at 24Vdc) ✓ real time clock with replaceable CR1025 Lithium / Manganese Dioxide back-up battery ✓... -
Page 10: Usage And Connections
Usage and connections STRATO PI BASE CONNECTION DIAGRAM Hardware Installation Strato Pi Base board The Strato Pi Base board is supplied with all connectors pre-installed. No soldering is required. You should connect Strato Pi to Raspberry Pi through the GPIO connector. Use appropriate turrets/spacers to firmly bolt the two boards together, ensuring that no conductive part of one board touches any part of the other board. -
Page 11: Strato Pi Base Server
Strato Pi Base server The Strato Pi Base server comes pre-assembled with a Raspberry Pi 3 Model B or B+ board, in a plastic standard DIN-rail case. There is no need to open the case, unless a change in the RS-485 termination resistors is required (see below). - Page 12 NOTICE Before opening the Strato Pi Base case, disconnect all power sources and any connection to external devices, including USB cables. Use a non-conductive pin or small tool to help extract the battery from its holder. Insert the new battery with a gentle push. You don't need tools to insert the battery. The battery is held into place by a spring contact.
-
Page 13: Terminal Block
Terminal block Strato Pi Base has a 9 positions terminal block for power and serial connections. The maximum conductor cross section is 1.5 mm (16 AWG), or 0.5 mm when using ferrules (highly recommended). Recommended stripping length is 5 mm. Screw thread is M2. -
Page 14: Dedicated Gpio Pins
STRATO PI BASE POWER SUPPLY STAGE TYPICAL IN/OUT VOLTAGE AND CURRENT Dedicated GPIO pins Strato Pi uses some of the Raspberry Pi’s GPIO pins. These pins should not be used for other functions. GPIO pin Direction Description GPIO2/SDA C SDA line for the real time clock GPIO3/SCL C SCL line for the real time clock GPIO14/TXD... -
Page 15: Software Installation And Configuration
Run the following commands to download and install the Strato Pi utility: $ cd /usr/local/bin $ sudo wget http://sferalabs.cc/files/strato/strato $ sudo chmod 755 strato You can run the Strato Pi utility without arguments to print its options: $ strato... -
Page 16: Testing The Real Time Clock
$ chmod 755 rtc-install $ sudo ./rtc-install If the script completes with no errors, delete the installation script and reboot: $ rm rtc-install $ sudo reboot Testing the Real Time Clock Assuming you are connected to the Internet and your Pi was able to reach a public NTP (Network Time Protocol) server, you should see the current date and time using the “date”... -
Page 17: Disabling Bluetooth, Wifi And The Serial Console
Disabling Bluetooth, WiFi and the serial console On Raspberry Pi 3, the main UART is used for Bluetooth, and the TX/RX pins on the GPIO connector are controlled by a limited function Mini UART. To route the main UART to the RX/TX pins that are connected to the Strato Pi serial ports you should disable Bluetooth. -
Page 18: Using Strato Pi Base
Using Strato Pi Base Real Time Clock Strato Pi Base has a hardware real time clock with a dedicated long-life non-rechargeable back-up battery. Once the RTC modules and configuration files are properly installed, you will simply use the date and time commands to control the hardware clock. Serial port Strato Pi Base uses the Raspberry Pi standard UART TX/RX pins on the GPIO connector to implement a standard serial port with support for both RS-232 and RS-485. -
Page 19: Buzzer
RS-485 JUMPERS POSITION Buzzer Strato Pi Base has an on-board buzzer that can be controlled using GPIO20. Simply set GPIO20 to high to emit a continuous sound, and back to low to stop. The buzzer is not intended to emit sound indefinitely and could be damaged doing so. The Strato Pi utility has several commands to control the buzzer. -
Page 20: Hardware Watchdog
Hardware watchdog Strato Pi Base implements a dedicated hardware watchdog circuit that can be used to perform a full power cycle of the Raspberry Pi. Being controlled by Raspberry Pi’s GPIO pins, it is extremely easy to control watchdog operation using simple custom scripts in your application. The watchdog is normally disabled. -
Page 21: Block Diagram
Block diagram STRATO PI BASE BLOCK DIAGRAM Strato Pi Base User Guide... -
Page 22: Technical Specifications
Technical specifications Power supply 9-28V⎓ (VDC) Reverse polarity protection with 1.1A resettable fuse. Surge protection up to ±1000V/2ohms 1.2/50μs 150mA w/o Ethernet Current consumption at VS+ 12V⎓ 180mA with Ethernet and RS-485 including Raspberry Pi 3 current, with low CPU/GPU load and no USB devices connected Actual current consumption may vary based on working conditions... - Page 23 Internal RTCC circuit with backup lithium battery. Only use CR1025 Lithium / Manganese Dioxide (Li/ MnO2) batteries. Real time clock Expected battery life without main power supply: ~2 years Housing standard 4M for DIN rail Operating temperature 0…+50 °C Storage temperature -20…+70 °C Protection degree IP20...
-
Page 24: Dimensions
Dimensions DIMENSIONS (mm) Strato Pi Base User Guide... -
Page 25: Disposal
Disposal Waste Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems). This marking on the product, accessories or literature indicates that the product should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources. -
Page 26: Conformity Information
✓ 2011/65/UE (RoHS) The declaration of conformity is available on the internet at the following address: https:// www.sferalabs.cc/strato-pi/ This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 27 Compliance information for Raspberry Pi 3 Model B Strato Pi Base server model SPMB21X contains a standard Raspberry Pi 3 Model B single board computer. This board has WiFi and Bluetooth radios. It is user accessible and replaceable.
- Page 28 Raspberry Pi 3 Model B+ is in conformity with the essential requirements and other relevant requirements of the Radio Equipment Directive 2014/53/EU. Raspberry Pi 3 Model B+ FCC IDENTIFIER: 2ABCB-RPI3BP The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be colocated or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multitransmitter product guidelines.
