hardware watchdog can also control the microSD switch matrix, swapping the boot
card in case the watchdog is triggered
✓ powerful and user-programmable 32 bit microcontroller (ATSAME54), with 1 MB
program memory and 256 KB RAM. The microcontroller is interconnected to the
Raspberry Pi via I2C, USB and CAN. It can also take direct low-level control of all serial
ports and digital as well as analog I/O
✓ integrated Serial Wire Debug (SWD) interface to the Iono Pi Max microcontroller,
allowing in-field firmware upgrades, but also development and debugging, directly from
the Raspberry Pi
✓ embedded Microchip ATECC608 secure element chip
✓ front-panel RGB LEDs for power supply and serial line activity, can also be directly
controlled by the Raspberry Pi
✓ on-board piezoelectric buzzer, for acoustic feedback
✓ front-panel push-button, connected to a GPIO pin
✓ power supply, serial and I/O connections on pluggable terminal blocks
✓ internal temperature sensors for system temperature monitoring
✓ internal fan, controlled by the microcontroller based on current load and internal
temperature
✓ packaged in a compact 6 modules DIN rail case
✓ optional earthquake sensor module
Iono Pi Max Solo:
✓ compatible with Raspberry Pi Compute Module 3, Raspberry Pi Compute Module 3
Lite, Raspberry Pi Compute Module 3+ 8GB, Raspberry Pi Compute Module 3+ 16GB,
Raspberry Pi Compute Module 3+ 32GB, Raspberry Pi Compute Module 3+ Lite,
Raspberry Pi Compute Module 4S 8GB, Raspberry Pi Compute Module 4S 16GB,
Raspberry Pi Compute Module 4S 32GB, Raspberry Pi Compute Module 4S Lite
Iono Pi Max 3+:
✓ pre-installed and tested Raspberry Pi Compute Module 3+, Lite, 8GB, 16GB or 32GB
eMMC versions
Iono Pi Max 4S:
✓ pre-installed and tested Raspberry Pi Compute Module 4S, Lite, 8GB, 16GB or 32GB
eMMC versions
