Sferalabs Iono Pi Max v2 3+ Lite User Manual page 46

Bit 11-8 BAUD: RS-485 baud rate for TX-enable automatic control
2 = 1200
3 = 2400
4 = 4800
5 = 9600
6 = 19200
7 = 38400
8 = 57600
9 = 115200
Bit 13-12 PAR: RS-485 parity for TX-enable automatic control
0 = none
1 = odd
2 = even
Bit 14 NBIT: RS-485 data bits for TX-enable automatic control
0 = 7 bits
1 = 8 bits
Bit 15 STP: RS-485 stop bits for TX-enable automatic control
0 = 1 bit
1 = 2 bits
Register 27
Bit 0 TXE: RS-485 TX-enable line manual control
0 = transmission disabled
1 = transmission enabled
WATCHDOG
ADDR
15 14 13
29
30
31
32
Register 29
Bit 0 MOD: enable mode
0 = watchdog normally disabled (default)
1 = watchdog always enabled
46
BYTE 1
12 11 10 9
DOWN DELAY
8 7 6 5
TIMEOUT
SD SWITCH
BYTE 0
4 3 2 1
MOD
Iono Pi Max User Guide
R/W
0
R/W
R/W
R/W
R/W
