Bit 11 TEMP: system temperature probes status
0 = probes OK
1 = probes failure
Bit 12 232 ERR: RS-232 interface status
0 = RS-232 OK
1 = RS-232 failure
Bit 13 485 ERR: RS-485 interface status
0 = RS-485 OK
1 = RS-485 failure
POWER MONITORING
ADDR
15 14 13
145
146
147
148
149
150
Register 145
Bit 15-0 VIN V: voltage measured on power supply input, in mV
Register 146
Bit 15-0 VIN I: current drain measured on power supply input, in mA
Register 147
Bit 15-0 BAT V: voltage measured on battery charger output, in mV
Register 148
Bit 15-0 BAT I: current drain measured on battery charger output, in mA
Register 149
Bit 15-0 VSO V: voltage measured on VSO, in mV
Register 150
Bit 15-0 VSO I: current drain measured on VSO, in mA
57
BYTE 1
12 11 10 9 8 7 6 5
VIN V
VIN I
BAT V
BAT I
VSO V
VSO I
BYTE 0
4 3 2 1
Iono Pi Max User Guide
R/W
0
R
R
R
R
R
R
