SYSTEM STATUS
ADDR
15 14 13
485
137
ERR
Register 140
Bit 0 FAN: fan status
0 = inactive
1 = active
Bit 1 5VO PROT: 5VO output protection
0 = output OK
1 = protection enabled, output temporarily disabled
Bit 2 5VX PROT: 5VX output protection
0 = output OK
1 = protection enabled, output temporarily disabled
Bit 3 EXP AUX: EXP bus auxiliary line status
0 = EXP bus auxiliary line low
1 = EXP bus auxiliary line high
Bit 4 VSO PROT: VSO output protection
0 = output OK
1 = protection enabled, output temporarily disabled
Bit 5, 6 AOx PROT: AOx output protection
0 = output OK
1 = protection enabled, output temporarily disabled
Bit 7 VSO ERR: VSO control status
0 = VSO control OK
1 = VSO control failure
Bit 8 ADC ERR: analog converter for analog inputs status
0 = ADC OK
1 = ADC failure
Bit 9 UPS ERR: UPS status
0 = UPS OK
1 = UPS failure
Bit 10 LED: LEDs module control status
0 = module OK
1 = module failure
56
BYTE 1
12 11 10 9
232 LED UPS
TEMP
ERR ERR ERR
8 7 6 5
ADC VSO AO2 AO1
ERR ERR PROT PROT
BYTE 0
4 3 2 1
VSO EXP 5VX 5VO
PROT AUX PROT PROT
Iono Pi Max User Guide
R/W
0
FAN R
