Register 37
Bit 15-0 DOWN DELAY: shutdown delay from the moment it is enabled, in seconds
(default = 60)
Register 38
Bit 15-0 OFF TIME: duration of power-off, in seconds (default = 5)
Register 39
Bit 15-0 UP DELAY: power-up delay after main power is restored, in seconds
(default = 0)
UPS
ADDR
15 14 13
43
44
45
46
48
Register 43
Bit 0 EN: UPS control
0 = disabled
1 = enabled (default)
Bit 1 BAT VOLT: battery voltage
0 = 12 V (default)
1 = 24 V
Register 44
Bit 15-0 CAPACITY: capacity of the battery connected to the UPS, in mAh.
Accepts values between 100 and 60000 (60Ah). Modifiable only when UPS is
disabled (default = 800)
Register 45
Bit 15-0 MAX CURRENT: UPS battery maximum charging current, in mA
0 = automatically derived from capacity (default)
N > 0 = limit current below the specified value. The automatically derived limit
still applies if lower than the set value
Register 46
Bit 15-0 DOWN DELAY: automatic power cycle timeout, in seconds.
0 = automatic power cycle disabled (default)
48
BYTE 1
12 11 10 9
MAX CURRENT
DOWN DELAY
CHARGE
8 7 6 5
CAPACITY
BAT
BYTE 0
4 3 2 1
BAT
VOLT
STAT
