6. Orient the Seat Frame (9) as shown.
Attach the Seat Frame (9) to the Seat Carriage
(7) with four M8 x 40mm Screws (28); start all
the Screws, and then tighten them.
7. Orient the Seat (10) as shown.
Attach the Seat (10) to the Seat Frame (9) with
four M6 x 40mm Screws (27) (only two Screws
are shown); start all the Screws, and then
tighten them.
6
28
9
7
7
10
8
28
9
27
