- Page 1 9PX3K3U 9PX EBM 180 V Installation and user manual Copyright © 2016 EATON All rights reserved. Service and support: Call your local service representative 9PX3K3U US_EN...
- Page 2 SAFETY INSTRUCTIONS TRUCTIONS. This manual contains important instructions SAVE THESE INS that should be followed during installation and maintenance of the UPS and batteries. The 9PX models that are covered in this manual are intended for installation in an environment within 0 to 40°C, free of conductive contaminant. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
- Page 3 The system is not for use in a computer room AS DEFINED IN the standard for the Protection of Information Technology Equipment, ANSI/NFPA 75. Contact Eaton resellers to order a special battery kit, if needed to meet the ANSI/NFPA 75 requirement.
- Page 4 During the replacement of the Battery Module, it is imperative to use the same type and number of element as the original Battery Module provided with the UPS to maintain an identical level of performance and safety. In case of doubt, don’t hesitate to contact your EATON representative. •...
-
Page 5: Table Of Contents
Configuring battery settings ..................27 Retrieving the Event log ....................28 Retrieving the Fault log ....................28 6. Communication ................29 Communication ports ....................29 Eaton Intelligent Power Software suite ...............32 7. UPS maintenance ................33 7 .1 Equipment care ......................33 7 .2 Storing the equipment ....................33 7 .3... -
Page 6: Introduction
Before installing your 9PX, please read the booklet presenting the safety instructions. Then follow the indications in this manual. To discover the entire range of EATON products and the options available for the 9PX range, we invite you to visit our web site at www.eaton.com/powerquality or contact your EATON representative. - Page 7 - causing hours of lost productivity and expensive repairs. With the Eaton 9PX, you can safely eliminate the effects of power disturbances and guard the integrity of your equipment. Providing outstanding performance and reliability, the Eaton 9PX’s unique benefits include: •...
-
Page 8: Presentation
Description Weights Dimensions (inch/mm) (lb/kg) D x W x H 9PX3K3U 106 / 48 28.4 x 17.3 x 5.1 / 722 x 440 x 130 9PX EBM 180V 150 / 68 25.4 x 17.3 x 5.1 / 645 x 440 x 130... -
Page 9: Rear Panels
2. Presentation Rear panels 9PX3K3U RS232 communication port USB communication port Dry (relay) contacts communication port Connector for ROO (Remote On/Off) control Connectors for automatic recognition of an additional battery module Connector for RPO (Remote Power Off) control Slot for optional communication card... -
Page 10: Accessories
2. Presentation Accessories Part number Description 9PXEBM180RT Extended Battery Module Rack kit 9PX RK2PC 2-post Rack Kit 9PX Network-MS Network card Modbus-MS Modbus and network card Relay-MS Relay card MBP6K208 HotSwap MBP 6000 208 9PXTFMR5 5kVA Transformer 9PXPPDM1 6kVA PPDM (Type 1) 9PXPPDM2 6kVA PPDM (Type 2) BINTSYS... - Page 11 2. Presentation 9PXPPDM1 L6-30P input power cable L6-30R outlet for connection to UPS input L6-30P cable for connection to UPS output L14-30R 120V/240V outlet L6-30R 240V outlet 30A circuit breaker (6) 5-20R 120V outlets 20A circuit breaker 9PXPPDM2 Input/Output terminal blocks L6-30R outlet for connection to UPS input L6-30P cable for connection to UPS...
-
Page 12: Control Panel
2. Presentation Control panel The UPS has a five-button graphical LCD. It provides useful information about the UPS itself, load status, events, measurements and settings. Online mode Fault indicator (green) indicator (red) Battery mode Bypass mode indicator (orange) indicator (orange) Online mode 100% 2.0kW... -
Page 13: Lcd Description
2. Presentation LCD description After 5 minutes of inactivity, the LCD displays the screen saver. The LCD backlight automatically dims after 10 minutes of inactivity. Press any button to restore the screen. Operation status Online mode 100% Load/equipment status 2.0kW 60min Battery status 2.1kVA... -
Page 14: Display Functions
[Product type/model] / [Part/Serial number] / [UPS/NMC firmware] / [Com card IPv4], [Com card IPv6], [Com card MAC] / [Detected accessories] Register product Links to Eaton registration website User settings The following table displays the options that can be changed by the user. Submenu... - Page 15 2. Presentation Submenu Available settings Default settings Interrupt time If Bypass transfer is enabled, [10ms] Interrupt time: [10ms] [20ms] Define break duration when transfer on Bypass In/Out settings Overload [10%] … [102%] [102%] Load % when overload alarm occurs prealarm Redundancy [Unitary UPS] [Hot Standby] Unitary UPS...
-
Page 16: Installation
3. Installation Inspecting the equipment If any equipment has been damaged during shipment, keep the shipping cartons and packing materials for the carrier or place of purchase and file a claim for shipping damage. If you discover damage after acceptance, file a claim for concealed damage. To file a claim for shipping damage or concealed damage: 1. -
Page 17: Checking The Accessory Kit
3. Installation Checking the accessory kit • Verify that the following additional items are included with the UPS: (2)Tower stands Rack kit for 19-inch enclosures Cable gland for Output connection Additional cable gland for Input Network card-MS communication card RS232 communication cable USB communication cable User manual Safety instructions... - Page 18 3. Installation Connecting the internal battery Do not make unauthorized changes to the UPS; otherwise, damage may occur to your equipment and void your warranty. Do not connect the UPS to utility until installation is completed. To install the UPS: 1.
-
Page 19: Connecting The Ebm(S)
3. Installation Connecting the EBM(s) A small amount of arcing may occur when connecting an EBM to the UPS. This is normal and will not harm personnel. Insert the EBM cable into the UPS battery connector quickly and firmly. 1. Plug the EBM power cable(s) into the battery connector(s). Up to 12 EBMs may be connected to the UPS. -
Page 20: Tower Installation
3. Installation Tower installation If you ordered other UPS accessories, refer to specific user manuals to check the tower installation with the UPS. To install the cabinet: 1. Place the UPS on a flat, stable surface in its final location. 2. -
Page 21: Rack Installation
3. Installation Rack installation If you ordered other UPS accessories, refer to specific user manuals to check the rack installation with the UPS. • Prepare UPS for rack mounting. This step requires two people. The UPS is heavy. To ease its rack mounting, you can remove the battery pack from the UPS as explained below. - Page 22 3. Installation • Rack mounting of UPS, EBM, and accessory modules. Follow steps 1 to 4 for module mounting on the rails. The rails and necessary hardware are supplied by EATON. Page 22 9PX3K3U_EN...
-
Page 23: Installation Requirements
3. Installation Installation requirements Recommended protective devices and cable cross-sections 1. Recommended upstream protection UPS power rating Upstream circuit breaker 9PX3K3U D curve – 30A 2 poles circuit breaker to UPS Normal AC source N(L2) G N(L2) L1 2. Recommended cable cross-sections... -
Page 24: Power Cables Connection
Access to terminal blocks 1. Remove the terminal blocks cover (one screw) 2. Punch the knockouts and insert the cables/conduits inside Note: the L6-30P input power cable is attached by Eaton. • High leakage current: Earth connection essential before connecting supply. -
Page 25: Operation
The UPS should be in Online mode. The internal batteries charge to 90% capacity in less than 3 hours. However, Eaton recommends that the batteries charge for 48 hours after installation or long-term storage. Starting the UPS on Battery Before using this feature, the UPS must have been powered by utility power with output enabled at least once. -
Page 26: Operating Modes
5. Operation Operating modes The Eaton 9PX front panel indicates the UPS status through the UPS indicators, see page 14. Online mode During Online mode, the indicator illuminates solid and the UPS is powered from the utility. The UPS monitors and charges the batteries as needed and provides filtered power protection to your equipment. -
Page 27: Setting High Efficiency Mode
Bypass voltage monitoring: if Bypass quality is not in tolerance, then the UPS will remain in Online mode. Eaton recommends to use the HE mode only to protect I/T equipment. To set the High Efficiency mode: 1. Put the UPS on Bypass: press any button to activate the menu options, select Control and Go to Bypass. -
Page 28: Retrieving The Event Log
5. Operation Retrieving the Event log To retrieve the Event log through the display: 1. Press any button to activate the menu options, then select Event log. 2. Scroll through the listed events. Retrieving the Fault log To retrieve the Fault log through the display: 1. -
Page 29: Communication
RS232 or USB communication port on the UPS. The UPS can now communicate with EATON power management software. • Relay output contacts The UPS incorporates four relay outputs; each information is available with a close or open contact. n.c. - Page 30 6. Communication • Remote On/Off Remote On/Off allows remote action of button to switch On/Off the UPS. Normally open When contact changes from open to closed, the UPS is switched-on (or stays On). When contact changes from closed to open, the UPS is switched-off (or stays Off). On/Off control via button has priority over the remote control.
- Page 31 6. Communication Remote control connection and test 1. Check the UPS is shut down and the electrical supply network disconnected. 2. Remove RPO connector from the UPS by unfitting the screws. 3. Connect a normally closed volt-free contact between the two pins of connector. Contact open: shut down of UPS To return to normal operation, deactivate the external remote shut down contact and restart the UPS from the front panel.
-
Page 32: Eaton Intelligent Power Software Suite
It also gives you a complete record of critical power events, and it notifies you of important UPS or power information. If there is a power outage and the 9PX UPS battery power becomes low, Eaton Software suite can automatically shut down your computer system to protect your data before the UPS shutdown occurs. -
Page 33: Ups Maintenance
If you store the equipment for a long period, recharge the battery every 6 months by connecting the UPS to utility power. The internal batteries charge to 90% capacity in less than 3 hours. However, Eaton recommends that the batteries charge for 48 hours after long-term storage. Check the battery recharge date on the shipping carton label. -
Page 34: Replacing Batteries
7. UPS maintenance Replacing batteries DO NOT DISCONNECT the batteries while the UPS is in Battery mode. Batteries can be replaced easily without turning off the UPS or disconnecting the load. If you prefer to remove input power to change the batteries, see "UPS Shutdown" on page 25. Consider all warnings, cautions, and notes before replacing batteries. - Page 35 7. UPS maintenance • Replacing the internal battery The internal battery is heavy. Use caution when handling the heavy batteries. To replace the battery pack: 1. Remove the center cover of the front panel 2. Remove the two screws to open the left side of the front panel 3.
- Page 36 7. UPS maintenance • Replacing the EBM(s) The EBM is heavy. Lifting the cabinet into a rack requires a minimum of two people. To replace the EBM(s): 1. Unplug the EBM power cable and battery detection cable from the UPS. If additional EBM(s) are installed, unplug the EBM power cable and battery detection cable from each EBM.
-
Page 37: Replacing The Ups Equipped With A Hotswap Mbp Or With A Ppdm
7. UPS maintenance Replacing the UPS equipped with a HotSwap MBP or with a PPDM The HotSwap MBP as well as the PPDM allows to service or replace the UPS without interrupting the connected loads. Refer to the specific user manual for more information about this accessory. •... -
Page 38: Troubleshooting
8. Troubleshooting The Eaton 9PX is designed for durable, automatic operation and also alerts you whenever potential operating problems may occur. Usually the alarms shown by the control panel do not mean that the output power is affected. Instead, they are preventive alarms intended to alert the user. - Page 39 8. Troubleshooting UPS overtemperature The UPS internal temperature is If the UPS transferred to Bypass too high or a fan has failed. mode, the UPS will return to normal operation when the temperature drops At the warning level, the UPS 5°C below the warning level.
-
Page 40: Silencing The Alarm
8. Troubleshooting Silencing the alarm Press the ESC (Escape) button on the front panel display to silence the alarm. Check the alarm condition and perform the applicable action to resolve the condition. If the alarm status changes, the alarm beeps again, overriding the previous alarm silencing. -
Page 41: Specifications
9. Specifications Model specifications Table 1. Power Module model list Model Power ratings 9PX3K3U 3000VA / 3000W Table 2. Extended Battery Module model list Model Configuration Battery voltage For power ratings 9PXEBM180RT Rack / Tower 180Vdc 3000VA Table 3. Weights and dimensions... - Page 42 High Efficiency mode: 10ms maximum (due to loss of utility) Power factor Load crest ratio 3 to 1 Table 7. Electrical output connections Model Output connection 9PX3K3U Hardwired (2) L6-30R (2) L6-20R Table 8. Environmental and safety EMC certifications IEC/EN 62040-1: 2008 IEC/EN 62040-2: 2006 Cat.
- Page 43 Up to 10,000 meters (32,808 ft) above sea level Audible noise < 45 dBA at 1 meter typical Table 9. Battery Internal batteries Rack / Tower 9PX3K3U: 180Vdc 9PXEBM180RT: 180Vdc configuration Type Sealed, maintenance-free, valve-regulated, lead-acid, with minimum 3-year float service life at 25°C (77°F).
- Page 44 Scheduling of the EATON Field Service Engineers typically should be done 7 to 10 days before they are required on-site. If the startup of the UPS is critical to maintaining your schedule, please contact EATON, to insure a safe installation and start-up that will maintain the EATON warranty and insure smooth performance.
-
Page 45: Glossary
10. Glossary Bypass AC source Source supplying the bypass line. The equipment can be transferred to the bypass line if an overload occurs on the UPS output, for maintenance or in the event of a malfunction. Frequency converter Operating mode used to convert the AC-power frequency between the UPS input and output (50Hz ->... - Page 46 Page 46 9PX3K3U_EN...
