- Page 1 Eaton 9PX Gen2 Advanced User Guide MBP6KiG2 MBP11KiG2 Copyright © 2025 EATON All rights reserved. English...
-
Page 2: Table Of Contents
Table of Content Safety instructions ....................... 3 Special symbols ........................4 Introduction ........................5 2.1 Environmental protection ........................5 2.2 Benefits ..............................6 Presentation ........................6 4.1 Weights and dimensions ........................... 6 4.2 Rear Panel ..............................7 Installation .......................... 8 5.1 Inspecting the equipment: MBP package content.................. -
Page 3: Safety Instructions
• The admissible storage temperature range is -15ºC to +60ºC. Special precautions • The HotSwap MBP is designed to work with approved EATON UPS (contact your Eaton reseller for more information) • All repairs and service should be performed by AUTHORIZED SERVICE PERSONNEL ONLY. There are NO USER SERVICEABLE... -
Page 4: Special Symbols
2 Special symbols The following are examples of symbols used on the UPS or accessories to alert you to important information: DANGER: Dangerous voltage levels are present within the UPS. The UPS has its own internal power source (the battery). Consequently, the power outlets may be energized even if the UPS is disconnected from the AC power source. -
Page 5: Introduction
Before installing your HotSwap MBP with your UPS, please read first the safety instructions. Then follow the indications in this manual, which completes the UPS Installation and User Manual. To discover the entire range of EATON products, we invite you to visit our web site at www.eaton.com/ powerquality or contact your EATON representative 2.1 Environmental protection... -
Page 6: Benefits
2.2 Benefits The Eaton® HotSwap MBP module makes it possible to service or even replace the UPS without affecting the connected loads (HotSwap function). You can safely eliminate the effects of UPS maintenance and guard the integrity of your equipment. -
Page 7: Rear Panel
4.2 Rear Panel MBP rear panels MBP6KiG2 ① Input/Output terminal blocks ② Normal AC source switch ③ Input/Output to UPS ④ Manual Bypass switch ⑤ MBP-Detection connector to the UPS MBP11KiG2 ⑥ "Bypass" mode red light ⑦ UPS supply green light Sockets: ⑧... -
Page 8: Installation
5 Installation 5.1 Inspecting the equipment: MBP package content If any equipment has been damaged during shipment, keep the shipping cartons and packing materials for the carrier or place of purchase and file a claim for shipping damage. If you discover damage after acceptance, file a claim for concealed damage. -
Page 9: Mbp Connection To Ups
5.2 MBP connection to UPS Note: In the configuration "UPS + EBM", the MBP must be mounted at the back of EBM. Mechanical installation in rack position For the MBP used with 8000VA and 11000VA UPS, depending on the configuration, there are two different assemblies, identified with letters (UPS only) and (UPS+EBM) - Page 10 Follow the steps below to install the MBP in rack position. 1. Screw the ears on each MBP side. MBP6KiG2 used with 5000VA and 6000VA UPS MBP11KiG2 used with 8000VA and 11000VA UPS 2. Mount the MBP with its ears on the UPS rack. MBP6KiG2 used with 5000VA and 6000VA UPS MBP11KiG2 used with 8000VA and 11000VA UPS...
- Page 11 Mechanical installation in tower position Depending on the configuration, there are four different assemblies, identified with letters A, B, C and D. The different ways to mount the MBP with the UPS or the "UPS+EBM" are identified by the A, B, C & D letters. Final assembly position: MBP6KiG2 used with 5000VA and 6000VA UPS MBP11KiG2 used with 8000VA and 11000VA UPS...
- Page 12 Follow the steps below to install the MBP in tower position. Screw the ears on each MBP side. MBP6KiG2 used with 5000VA and 6000VA UPS MBP11KiG2 used with 8000VA and 11000VA UPS Mount the MBP with its ears on the UPS or EBM MBP6KiG2 used with 5000VA and 6000VA UPS MBP11KiG2 used with 8000VA and 11000VA UPS...
- Page 13 MBP electrical connection Caution: Manually trip the input circuit breaker of your installation before connecting the supply cables. Access to the terminal block, remove the circular covers and screw the cable glands. MBP11KiG2 used with 8000VA and 11000VA UPS MBP6KiG2 used with 5000VA and 6000VA UPS...
- Page 14 Insert the electrical cables. Follow below instructions for upstream protection and cable cross section. Use copper cable only, and not aluminum. Recommended upstream protection The upstream circuit breaker for Normal AC/Bypass AC must be easily accessible. The unit can be disconnected from AC power source by opening this circuit breaker.
- Page 15 Strip the copper supply cable keeping the Earth cable longer for safety purpose. Insert the cables MBP6KiG2 used with 5000VA and 6000VA UPS MBP11KiG2 used with 8000VA and 11000VA UPS Tighten well the cable glands MBP6KiG2 used with 5000VA and 6000VA UPS MBP11KiG2 used with 8000VA and 11000VA UPS Close the I/O box terminal MBP6KiG2 used with 5000VA and 6000VA UPS...
- Page 16 Connection between MPB and UPS For the electrical connection on the UPS side, follow the steps described in the chapter "Hardwired connection" Connect the MBP cord set (For 6k MBP only) Connect the MBP detection cable to the UPS Power up your installation Switch on the input circuit breaker of your installation.
-
Page 17: Operation
6 Operation 6.1 UPS start-up with HotSwap MBP Verify that the total equipment ratings do not exceed the UPS capacity to prevent an overload alarm. 1. Check that the UPS is correctly connected to the HotSwap MBP. If the UPS if equipped with outlets, those outlets can no longer be used (loads can only be connected to the MBP outlets or the MBP Output terminal blocks 2. -
Page 18: Ups Maintenance With Hotswap Mbp
7 UPS maintenance with HotSwap MBP 7.1 UPS replacement with HotSwap MBP UPS Removing (please follow the MANDATORY step below). UPS replacement must be performed by qualified person only. MBP6KiG2 For the following steps, refer to the UPS User Manual : •... - Page 19 MBP11KiG2: UPS replacement must be performed by qualified person only. BYPASS For the following steps, refer to the UPS User Manual : • Put the UPS in “Bypass mode” (“Control -> Go to bypass”). • Verify that the UPS is on Bypass mode by checking UPS display panel Set the MBP manual Bypass switch to "Bypass"...
- Page 20 Return to normal operation: Check that the new UPS is correctly connected to the MBP, as described below: MBP6KiG2: • After opening the UPS I/O terminal blocks cover, connect to UPS the 2 power cables, and the MBP detection cable, of the MBP I/O cord Set •...
-
Page 21: Ups Maintenance With Hotswap Mbp
7.2 UPS maintenance with HotSwap MBP Go to maintenance Bypass operation (please follow the MANDATORY steps below): For the following steps, refer to the UPS User Manual • Put the UPS in " Bypass mode" BYPASS • Verify that the UPS is on Bypass mode by checking UPS display panel 2. -
Page 22: Specification And Technical Characteristics
8 Specification and technical characteristics MBP6KiG2 MBP11KiG2 Input Terminal blocks Input Bypass Terminal Blocks Output 1 x C39 + 1 gang of 2 x C39 & 2x C13 4 x C39 Terminal blocks Terminal blocks Overall dimensions D x W x H (mm / inch) 125x177x130 285x130x130 4.9x7.0x5.1...
