Wiring diagram with T-Harness (THFON1)
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
OBDII
Diagnostic 16-pin Connector
BCM
(passenger side, behind glove box)
6 amp
diodes
C2280A (BCM)
(green 42-pin conn.
on BCM)
22 1
23 2
(+) Parking Light (left):
24 3
Yellow/Blue, pin 1
25 4
26 5
27 6
(+) Parking Light (right):
28 7
Brown/Yellow, pin 26
29 8
30 9
31 10
32 11
33 12
34 13
35 14
36 15
37 16
38 17
39 18
40 19
41 20
42 21
6 933.FORD4 3.25.198.12 2014 Ford Focus
©2023 Directed. All rights
THFON1
(optional T-Harness)
female
Refer to the Optional Starter disable connection
section for relay and connection details.
male
C2280C (BCM)
(blue 60-pin conn.
on BCM)
41 21 1
42 22 2
Cut
43 23 3
44 24 4
45 25 5
46 26 6
Driver Door Trigger:
47 27 7
Green/Violet,
48 28 8
49 29 9
50 30 10
51 31 11
52 32 12
(-) Lock/Unlock:
53 33 13
Brown, pin 11
54 34 14
55 35 15
56 36 16
57 37 17
58 38 18
59 39 19
60 40 20
Ignition
Barrel
Ignition Switch
(black 7-pin conn.)
(
(-) GWA Output: Blue/White
(+) Siren Output: Brown/Red
Siren
Hood Pin
(-) Hood Input: Gray
(+) Parking Light Output: White
(-) Lock/Unlock Output: Lt. Green/Black
RAP Off Interrupt (vehicle side): Lt. Green/White
RAP Off Interrupt (connector side): Lt. Green
(-) Trunk/Hatch/Power Liftgate
Release Output: Red/White
C2280B (BCM)
(brown 60-pin conn.
on BCM)
41 21 1
42 22 2
43 23 3
44 24 4
45 25 5
46 26 6
47 27 7
48 28 8
pin 45
49 29 9
50 30 10
(-) Trunk Release:
51 31 11
Brown, pin 49
52 32 12
53 33 13
54 34 14
55 35 15
56 36 16
57 37 17
58 38 18
59 39 19
60 40 20
).
P.A.T.S.
(black 4-pin conn.)
8-pin White Connector
22-pin White Connector
IMPORTANT:
Position the
fuses correctly!
12-pin Black Connector
10-pin White Connector
Slide to open
Legend:
Mandatory Connections
Security Only
Remote Start Only
Remote Start + Security
