Directed Directechs DB3+ Installation Manual page 10

Module
Conn./Pin Color Description
H2/18 Orange/Black (+) Instant Alarm Input
H2/19 Blue (-) Trunk Input
H2/20 Green (-) Door Input
H2/21 Gray
(-) Hood Switch Input
H2/22 Violet/White (AC) Tach Input
Main harness, 12-pin black connector (H3)
Module
Conn./Pin Color Description
H3/1 Blue/White Relay N.C. - No Connection
H3/2 Blue/Red Relay N.O. - (+) 12V Input
H3/3 Blue Relay COM. - (+) Ignition Output
H3/4 White/Brown Relay N.C. - No Connection
H3/5 White Relay COM. - (+) Parking Light Output
H3/6 Red (+) 12 Volt Input
H3/7 Lt. Green/Red Relay N.O. - No Connection
H3/8 Lt. Green Relay COM. - RAP Off Interrupt (conn. side)
H3/9 Lt. Green/White Relay N.C. - RAP Off Interrupt (vehicle side)
H3/10 Black (-) Ground
H3/11 White Relay COM. - (+) Parking Light Output
H3/12 Red (+) 12V Input
Relay harness, 10-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 N/A No Connection
H4/2 Red/Black (+) 12 Volt Input
H4/3 Pink/Black Flex Relay (pin 87a)
H4/4 Pink/White (+) Flex Relay Output
H4/5 Red (+) 12 Volt Input
H4/6 Green Starter Disable (key side)
H4/7 Violet (+) Starter Output
H4/8 Orange (+) Accessory Output
H4/9 Red/White (+) 12 Volt Input
10 933.FORD4 3.25.198.12 2014 Ford Focus
©2023 Directed. All rights
Connects To
Wire Location
No Connection
No Connection
No Connection
[1] The installation of an aftermarket hood pin is only required on vehicles
that are not equipped with a factory hood pin or if not supported in
data.
No Connection
Connects To
Wire Location
No Connection
BCM behind glove box, green 2 pin plug (G), pin 2
BCM behind glove box, blue 60 pin plug (C), pin 43
No Connection
Must use two 6A diodes.
BCM behind glove box, green 42 pin plug (A), pins 1, 26
BCM behind glove box, green 2 pin plug (G), pin 2
No Connection
BCM behind glove box, brown 60 pin plug (B), pin 45
BCM behind glove box, brown 60 pin plug (B), pin 45
Must use two 6A diodes.
BCM behind glove box, green 42 pin plug (A), pins 1, 26
BCM behind glove box, green 2 pin plug (G), pin 2
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color Connection
(+/-) Wire Color Connection
+ red (50A) Mandatory
+ brown/yellow Mandatory
+ yellow/blue (L); Mandatory
brown/yellow (R)
+ red (50A) Mandatory
- N.C. green/violet Remote Start
Only
- N.C. green/violet Remote Start
Only
(chassis ground) Mandatory
+ yellow/blue (L); Mandatory
brown/yellow (R)
+ red (50A) Mandatory
(+/-) Wire Color Connection
