Black Low Height Microphone Desk Mount
Instruction Manual
SKU: STAND-MIC03L
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-mic03l
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Related Manuals for Vivo STAND-MIC03L
Summary of Contents for Vivo STAND-MIC03L
- Page 1 Black Low Height Microphone Desk Mount Instruction Manual SKU: STAND-MIC03L Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-mic03l GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. - Page 3 STEP 1 - Option A - Continued Apply Soft Pad (F) to inside of Clamp (C). Secure assembly to desktop by tightening knob on Clamp (C). Proceed to Step 2 on Page 5 STEP 1 - Option B - Grommet Mount Unscrew Clamp Screw (C1) on Clamp (C).
-
Page 4: Step 1 - Option B - Grommet Mount
STEP 1 - Option B - Grommet Mount Mount Grommet Plate (E) to Arm Base (D) using M5x12mm Screws (S-A) and 3mm Allen Wrench (T-A), making sure the tapered holes are facing away from the Arm Base. Remove adhesive backing from Soft Pad (F) and adhere to Grommet Plate (E). - Page 5 STEP 2 Loosen the set screw on the Arm Base (D), using 3mm Allen Wrench (T-A) then install Lower Mic Arm (B). Tighten set screw using 3mm Allen Wrench (T-A). Loosen Set Screw Tighten Set Screw STEP 3 Loosen the set screw on the Lower Mic Arm (B) using 3mm Allen Wrench (T-A), then install Upper Mic Arm (A).
- Page 6 Step 4 Detach cable management trays from mic arms by sliding them towards the front of the mic stand. Run mic cable under the mic arms and reattach cable management trays.
- Page 7 Adjust as Desired To adjust mic angle, loosen the knob and set as desired. Re-tighten knob when set. Loosen Joint Screw on Upper Arm (A) using 3mm Allen Wrench (T-A) to adjust arm to desired height.
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
