Pneumatic Arm Dual Monitor Desk Mount
Instruction Manual
SKU: STAND-V002K,W
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v002k
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STAND-V002W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vivo STAND-V002W

Summary of Contents for Vivo STAND-V002W

  • Page 1 Pneumatic Arm Dual Monitor Desk Mount Instruction Manual SKU: STAND-V002K,W Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v002k GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303...
  • Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3 ASSEMBLY STEPS STEP 1 Loosen the screws and disassemble the Clamp (D) using the 4mm Allen Wrench (T-A). STEP 2 OPTION A: Clamp Installation OPTION B: Grommet Base Installation Attach Clamp Brace (D1) to Pole (C) using For grommet hole attachment only, cut Soft Pad the M6x16mm Screws (S-B) and 4mm Allen (G) along the indentations.
  • Page 4 STEP 2 (Continued) OPTION B: Grommet Installation OPTION A: Clamp Installation If not using an existing through-hole, using a For thinner desktops, re-attach Clamp (D2) to 10mm (⅜”) drill bit, drill through the desktop Clamp Brace (D1) and tighten the screws using at least 2”...
  • Page 5 STEP 3 Slide Arm (A) onto Pole (C) and tighten using 6mm Allen Wrench (T-B). Attach Cable Clip (E) to Pole (C). STEP 4 Attach VESA Plate (B) to the back of the monitor using Screws (M-A through M-D) and Washers (M-E).
  • Page 6 STEP 6 Adjust gas spring support in Arm (A) using 6mm Allen Wrench (T-B). Turning counter-clockwise increases support, and clockwise decreases. WARNING: Monitor must be installed on mount before making tension adjustments to the gas spring arm. Keep monitor in a straight orientation when making adjustments.
  • Page 7 STEP 8 Adjust tilt support using 6mm Allen Wrench (T-B). Store Allen Wrenches (T-A, T-B) in Cable Clip (E). Adjust as desired.
  • Page 8 AVG. RESPONSE TIME help@vivo-us.com (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
