Advantech MIO-3121 Startup Manual

MIO-3121 Mini-PCI to 4 COM Module
Startup Manual
Introduction
Advantech introduces its new MIO module, MIO-3121 with
Mini-PCI interface, an advanced 4 COM interface connec-
tion hub. Fully compliant to PCI local bus specification
3.0.UARTs fully S/W compatible with 16C550-type
devices. MiniPCI Type III Interface
Packing list
Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 MIO-3121 Mini-PCI to 4 COM Module
• 1 Startup manual
• 1 CD ROM for MIO-3121 Driver
• 1 FLAT CABLE 40P-2.0mm D-SUB
9P(M)/IDC 45cm
If any of these items are missing or damaged,
contact your distributor or sales representative
immediately.
Note 1: Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at:
www.adobe.com/products/acrobat/
readstep2.html(Acrobat is a trademark of
Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the MIO-3121 series Rev. A1.
Part No.2006312102
Specifications
• Mini PCI Type III Interface
• Chipset: OxmPCI954
• Four 16C950 High performance UART channels
• 8-bit Pass-through Local Bus (PCI Bridge)
• IEEE 1284 Compliant SPP/EPP/ECP Parallel port
• Efficient 32-bit, 33 MHz MiniPCI interface, fully compliant
• UART up to 20MHz with the crystal oscillator
• 3.3V operation (5V tolerance on selected I/Os) Connec-
• UART operation up to 60Mbps via external clock source.
• OS support: Win98, 2000, XP, NT4.0, Vista
Mechanical and Environmental
p/n: 1700000447
• Power Supply Voltage: 5V and 12V
• Size: 59.75mm x 52.75mm
• Operating Temperature: 0°C ~ 60°C (32°F ~ 140°F)
• Operating Humidity: 0% to 90% relative humidity, non-
• Compliance Certifications: CE; FCC
3rd Edition
Jan. 2008
to PCI Local Bus specification 3.0 and PCI Power Man-
agement Specification 1.1
tor: 40pins 2.0mm 20X2 Box Header
Up to 20MHz with the crystal oscillator
-40°C to 85°C (-40°F ~185°F)in Storage
condensing
MIO-3121 Startup Manual 1
