Advantech MIO-6254 Startup Manual

MIO-6254 Audio/DVI/TV-Out MIO
Module Startup Manual
Introduction
The most flexible interface for Embedded
Applications
Today is an embedded world, but many standard
embedded single board computers cannot 100% meet
application specifications because they are not flexible
enough to expand and develop the system.
A system design short cut
Module I/O (MIO) is an open pin definition interface
from Advantech. The MIO interface integrates the
most popular data buses into a high-density 160-pin
connector, including, PCI, USB, DVO, SMBus, LPC,
and AC97. With MIO, board engineers can speed up
system project design and expand the system easily.
Packing list
Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 MIO-6254
• 1 Startup manual
• 1 CD ROM for MIO-6254 Driver/Utility
• 1 screw kit
- copper stud x 5 pcs
- screw x 5 pcs
• 1 Mini Jumper kit (black)
- mini jumper x 10 pcs
If any of these items are missing or damaged, contact
your distributor or sales representative immediately.
Note 1: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
www.adobe.com/products/acrobat/
readstep2.html(Acrobat is a trademark of Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the MIO-6254 series Rev. A1.
Part No.2006625400
Specifications
• Chipset: AC97 Codec Realtek ALC202, Chrontel
• Audio Output: Dual Channel 6W Stereo Audio Speaker-
• Video Output: DVI, TV-Out, S-Video
Mechanical and Environmental
• Dimensions (L x W): 146mm (L) x 102mm (W)
• Operating Temperature: 0 ~ 60°C operation
• Operating Humidity: 0%~90% relative humity, non-con-
• Line-In, Speaker-Out, Mic-In
• MIO DVO to DVI interface
• TV-Out/S-Video
p/n: 1930000058
p/n: 1935030500
p/n: 1653302122
1st Edition
May 2006
CH7009A
Out, Line-In, Mic-In
densing
Features
MIO-6254 Startup Manual 1
