MIC-75G30
Dual GPU Expansion Module for Video AI Edge
Computing with MIC-7 Series
Startup Manual
Packing List
Before you begin installing your Expansion Module, please
make sure that the following items have been shipped:
• 1x MIC-75G30 i-Module
• 2x 4-pin phoenix connector
• 1x SATA cable (30 cm/11.8 in) 1
• 1x SATA cable (40 cm/15.7 in)
• 1x Mounting bracket (L)
• 1x Mounting bracket (R)
• 6x Screw for mounting bracket
• 2x GPU bracket
• 10x Screw for GPU bracket
• 5x Shock Proof Rubber
• 1x MIC-75G30 Start-up manual
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our sup-
port website for MIC-770 at:
http://advt.ch/MIC75G30
Register your products on our website and get 2
months extra warranty for free at:
http://www.register.advantech.com
This manual is for the MIC-75G30 Rev. A1.
Part No. 20415G3000
Printed in China
P/N: MIC-75G30-00A1
P/N: 1652003234
P/N: 1700017838
P/N: 1700020978-01
P/N: 1960005359T003
P/N: 1960094392N001
P/N: 1930007259-01
P/N: 1960094390N000
P/N: 1930005673-11
P/N: 1990000505T000
P/N: 20415G3000
1st Edition
August 2020
Specifications
Expansion Slot
• Slot 1 & 3: Blank
• Slot 2 & 4: PCIe × 16 (signal PCIe × 8) for GPU card
• Slot 5: PCIe × 4
Environment
• Operating Temp.: 0 ~ 40 °C/32 ~ 104 °F (35W CPU w/
industrial SSD)
• Vibration: With SSD: 1 Grms @ 5~500 Hz, random, 1 hr/
axis
• Shock: With SSD: 10G, IEC-68-2-27, half-sine wave,
11ms duration
Mechanical Information
• MIC-75G30 N.W.: 5 kg/11 lb; G.W.: 7 kg/15.4 lb
• Dimension (W×H×D): 280 × 192 × 385 mm (11 x 7.55 x
15.1 in ) (The dimensions provided are the dimensions of
the i-Module assembled in the MIC-77xx Series)
Note: By using MIC-7500 and MIC-7900, width will be
decreased by 4 mm / 0.15 in.
I/O Connectors
Connectors
No.
Item
1
DCIN1
2
PPCIE1
3
PPCIE2
4
PPCIE3
5
SATAPWR1
6
SATA1
7
SYSFAN1
8
SYSFAN2
9
GPUPWR1
10
GPUPWR2
11
GPUPWR3
12
GPUPWR4
13
DC12VOUT1
MIC-75G30 Startup Manual 1
Function
24V
in
DC
PCIe×16 slot
PCIe×16 slot
PCIe×4 slot
4-pin SATA power connector (5V)
SATA signal connector
4-pin fan connector
4-pin fan connector
6-pin power connector for GPU
card (12V, 17A)
6-pin power connector for GPU
card (12V, 17A)
6-pin power connector for GPU
card (12V, 17A)
6-pin power connector for GPU
card (12V, 17A)
4-pin power connector (12V, 5A)
