  • Page 2 MIC-3665A/B Dual Gigabit Ethernet PMC Function Modules Advantech CompactPCI™ Modular Industrial Computer...
  • Page 3 Copyright Notice This document is copyrighted, 2004. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of the original manufacturer.
  • Page 4 Product warranty Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for one year from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper installation.
  • Page 5 If any of these items are missing or damaged, contact your distributor or sales representative immediately. Technical Support and Sales Assistance If you have a technical question, please visit Advantech's support website, located at: http://support.advantech.com.tw. For more information about Advantech's products and sales service, please visit our homepage located at:...
  • Page 6 Tables and Figures Figure 2-1: MIC-3665 connector locations ........Figure 2-2: MIC-3665 front panel LEDs..........10 Table 2-1: MIC-3665 Gigabit Ethernet physical media support……………. Table 2-2: MIC-3665 LED Indicator definitions........Table A-1: MIC-3665 RJ-45 pin assignments........11 Table A-2: MIC-3665 PMC pin assignments……………………………………………. 12...
  • Page 7 Introduction...
  • Page 8 Gigabit performance in multi-mode fiber-optic networks. The fiber module also delivers high throughput while conserving CPU resources. The MIC-3665 is able to cache up to 64 packet descriptors in a single burst for efficient PCI bandwidth use. A large 64 Kbytes on–chip buffer maintains superior performance as available PCI bandwidth changes.
  • Page 9 1.2 Features •High performance wire speed, each port 1.9 Gb sustained raw throughput over 133/100/66 PCI-X •One adapter for all common platforms with driver support for Linux and Windows •Supports 33/66 MHz, 32/64 bit PCI interfaces and 100/133 MHz PCI-X •Installs in any PCI-capable CompactPCI system with a vacant PMC Mezzanine slot (PMC card) •Utilizes 3.3 volt power supply and contains onboard power regulators...
  • Page 10 1.3 Specifications • IEEE 802.3/802.3u 10Base-T/100Base-TX compatible • IEEE 802.3ab 1000Base-T compatible • IEEE 802.3z 1000Base-X (1000Base-SX, 1000base-LX) compatible*. • CompactPCI Mezzanine Specification Revision 1.0 • Complies with PCI Bus Specification 2.3 • RJ-45 connector: The RJ-45 connector can use IEEE 802.3 10 Base-T compliant Category 3, 4, or 5 cables.
  • Page 11 1.4 Safety Precautions Follow these simple precautions to protect yourself from harm and your system from damage. 1. To avoid electric shock, always disconnect the power from your system chassis before you work on it. Don't touch any components on the card or other cards while the system is on.
  • Page 12 Hardware and Drivers Installation...
  • Page 13 Retain the shipping carton and packing material for inspection by the carrier. We will make arrangements to repair or replace the unit after an inspection. When you handle the MIC-3665, remove it from its protective packaging by grasping the front metal panel. Keep the anti-vibration packing.
  • Page 14 JP1: Pin connector for LED Activity (for Fiber) 2.3 Card Installation The MIC-3665 is a PCI bus master PMC module. It can be installed only in a CompactPCI™ board which supports PMC interface. Improper installation of a card can easily damage the backplane of the chassis. The MIC-3665 install guide helps you to install and remove the module easily and safely.
  • Page 15 The link between the hub/switch and No link between the hub/switch and ACTIVITY adapter is active adapter LED blinks during data transmission SPEED* RED for 1000Base-T Operating in 10Base-T Green for 100Base-TX * MIC-3665 Fiber has no “speed” LEDs (only in 1000Base-X)
  • Page 16 2.6 Drivers/Utilities Installation The MIC-3665 supports PCI Plug and Play. The BIOS automatically detects the MIC-3665 while booting, and assigns an IRQ level and I/O address. No jumper or switch is required for user configuration. The MIC-3665 uses one Intel 82546GB Gigabit Ethernet controller chip.
  • Page 17 RJ-45 jack. This cable is responsible for the transmission and reception of all data over the network. Refer to the table and diagram below for the pin assignments. Table A-1: MIC-3665 RJ-45 pin assignments Pin Signal Description 1000Base-T...
  • Page 18 2. PMC pin assignments Table A-2: MIC-3665 PMC pin assignments P11 32-bit PCI NC TCK -12V NC 2 INITA# INTB# INTC# NC 6 NC BUSMODE1# NC INTD# PCI-RSVD NC 10 PCI-RSVD NC 12 GNT# REQ# 19 NC VIO AD[31] AD[28]...
  • Page 19 P21 32-bit PCI NC +12V TRST# NC 2 NC TMS NC 4 NC TDI PCI-RSVD NC 8 NC PCI-RSVD PCI-RSVD NC 10 11 NC BUSMODE2# +3.3V RST# BUSMODE3# NC 14 3.3V BUSMODE4# NC 16 17 NC PCI-RSVD AD[30] AD[29] AD[26] AD[24] 3.3V IDSEL...
  • Page 20 P31 32-bit NC PCI-RSVD GND C/BE[7]# C/BE[6]# C/BE[5]# C/BE[4]# NC VIO PAR64 AD[63] AD[62] AD[61] AD[60] AD[59] AD[58] AD[57] 21 NC VIO AD[56] AD[55] AD[54] AD[53] AD[52] AD[51] AD[50] AD[49] AD[48] AD[47] AD[46] AD[45] 39 NC VIO AD[44] AD[43] AD[42] AD[41] AD[40] AD[39]...
