Advantech MIO-6255 Startup Manual

MIO-6255 MIO/160 Module with 2 Cardbus
Startup Manual
Introduction
The most flexible interface for Embedded
Applications
Today is an embedded world, but many standard embed-
ded single board computers cannot 100% meet application
specifications because they are not flexible enough to
expand and develop the system.
A system design short cut
MIO/160 (Module I/O 160) is an open pin definition inter-
face from Advantech. The MIO/160 interface integrates the
most popular data buses into a high-density 160-pin con-
nector, including, PCI, USB, DVO, SMBus, LPC, and
AC97. With MIO/160, board engineers can speed up sys-
tem project design and expand the system easily.
Packing list
Before you begin installing your card, please make
sure that the following materials have been shipped:
• 1 MIO-6255
• 1 Start-up manual
• 1 Screw kit
- copper stud x 6 pcs
- screw x 6 pcs
If any of these items are missing or damaged, contact
your distributor or sales representative immediately.
Note 1: Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at:
http://www.adobe.com/products/acrobat/
readstep2.html(Acrobat is a trademark of
Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the MIO-6255 series Rev. A1.
Part No.2006625500
Specifications
• Chipset: Richo R5C486 Cardbus controller
• 2 Cardbus solt: Accepts type I/II/III PCMCIA Card.
• 16-bit Legacy Mode: YES(3E0/3E2 I/O port) support
• Data bus: 32-bit data bus (Compliant with PCI Bus
• PCI Interface: 3.3V interface(5V tolerant)
Mechanical and Environmental
• Dimensions (L x W): 120mm x 85mm, 4.7" x 3.3"
• Operating Temperature: 0 ~ 60°C operation
• Operating Humidity: 10%~90% relative humity, non-
• Complies with PC Card 95/97/98, Card-32(32bit), PCM-
• Support 2 PCMCIA slot, accepts type I/II/III PCMCIA
• MIO/160 interface
p/n: 9660250000
p/n: 1930000058
p/n: 1935030500
1st Edition
May. 2006
When type III Card used in slot 2, the slot 1 will be occu-
pied.
Specification 2.1)
condensing
Features
CIA V2.1/JEIDA4.2(16bit)
Cards
MIO-6255 Startup Manual 1
