Advantech MOS-2110Z-1201E User Manual

MOS-2110Z-1201E USB iDoor module, 2-Ch, PCIe I/F
User Manual
MOS-2110Z-1201E provides a simple method of adapting two USB 2.0 devices to a modern PCIe x 1 port. It accomplish by
incorporating the industry standard PCIe bridge chip. It is compliant with USB 2.0 specification, with xHCI (eXtensible Host
Controller Interface) specifications rev. 0.96.
MOS-2110Z-1201E supports simultaneous operation of multiple USB 2.0 and USB 1.1 devices, it can expands two external
USB 2.0 Hi-Speed ports on the system. Each USB port supplies maximum +5V/ 500mA power output to USB device.
Besides, MOS-2110Z-1201E support hot-swapping feature allows to connect/ disconnect devices without powering down
the system

1. Packing List

MOS-2110Z-1201E
USB controller miniPCIe card x1
USB wire cable with I/O bracket x1
Startup Manual x 1
Note: If any of these items are missing or damaged, please contact your distributor or sales representative immediately.

2. Initial Inspection

You should find the following items inside the shipping package:
USB controller miniPCIe card x1
USB wire cable with I/O bracket x1
Startup Manual x 1
The MOS-2110Z-1201E card harbors certain electronic components vulnerable to electrostatic discharge (ESD). ESD
could easily damage the integrated circuits and certain components if preventive measures are not carefully paid attention
to.
Before removing the card from the antistatic plastic bag, you should take following precautions to ward off possible ESD
damage:
Touch the metal part of your computer chassis with your hand to discharge static electricity accumulated on your
body. Or one can also use a grounding strap.
Touch the anti-static bag to a metal part of your computer chassis before opening the bag.
Take hold of the card only by the metal bracket when removing it out of the bag.
After taking out the card, first you should:
Inspect the card for any possible signs of external damage (loose or damaged components, etc.). If the card is visibly
damaged, please notify our service department or our local sales representative immediately. Avoid installing a damaged
card into your system.
MOS-2110Z-1201E User Manual 1
