Quick Start Guide
D104766X012
WARNING
To avoid static discharge from the plastic portion of the cover when flammable gases or dust are present, do not rub or
clean the cover with solvents. To do so could result in a spark that may cause the flammable gases or dust to explode,
resulting in personal injury or property damage. Clean with a mild detergent and water only.
NOTICE
Do not use sealing tape on pneumatic connections. This instrument contains small passages that may become obstructed
by detached sealing tape. Thread sealant paste should be used to seal and lubricate pneumatic threaded connections.
Step 1—Installation
Housing Variations
The DVC7K digital valve controller has a variety of different housing options.
The instrument comes with a Local User Interface (LUI), as shown in figure 1.
Figure 1. Local User Interface
HOUSING WITH LOCAL USER INTERFACE
DVC7K Digital Valve Controllers
October 2023
3
